MOLEX 39299167 Power Connector
The Mini-Fit Jr. vertical header with 4.20mm pitch is a reliable power connector designed for wire-to-board applications. Featuring dual rows and 16 circuits with a snap-in plastic PCB lock, it supports a maximum current of 9A per contact and a voltage of up to 600V. Made with durable materials, it is RoHS and REACH compliant, halogen-free, and operates effectively between -40°C to +105°C. Its through-hole termination, polarized design, and PCB retention ensure secure and versatile connectivity suitable for various electronic systems.
MOLEX 39299167 Power Connector Specifications:
- Pitch: 4.20mm
- Number of Circuits: 16
- Maximum Current: 9.0A per contact
- Maximum Voltage: 600V
- Operating Temperature Range: -40°C to +105°C
- Material - Resin: Flame-retardant, halogen-free
- Plating - Mating and Termination: 0.889um tin
- Termination Interface: Through Hole
- PCB Thickness - Recommended: 1.60mm
- Mating Guide: Polarized, shrouded, fully stackable
- Durability: Suitable for multiple mating cycles
- Packaging: Tray
- RoHS and REACH compliant, halogen-free, low-halogen
Buy the Buy Molex Mini-Fit Jr. Power Connector Part Number 39299167 Online
Order the Molex Mini-Fit Jr. Power Connector with part number 39299167 online today to ensure your electronic assembly has a durable, reliable, and compliant power connection solution. Ideal for wire-to-board power applications, it features 16 circuits with a 4.20mm pitch, supporting up to 9A current per contact at 600V. Its polarized, shrouded design with PCB retention guarantees secure installation while the RoHS and REACH compliance ensures environmentally safe operation. Purchase now for quick delivery and integrated connectivity solutions.
Buy Molex 39299167 now and experience unmatched reliability and performance in power and PCB connections for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 39299167?
You can click on the BUY or RFQ button to purchase 39299167 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 39299167?
You can download the 39299167 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 39299167?
MOLEX
