MOLEX 39532095 FFC/FPC Connector
This is a 1.25mm pitch easy-on FFC/FPC connector designed for through-hole mounting, featuring a vertical ZIF actuator with 9 circuits. It is RoHS and REACH compliant, UL certified, and made from phosphor bronze with tin-bismuth plating. The connector supports operating temperatures from -20°C to +80°C, with a maximum current of 1.0A per contact and a maximum voltage of 200V. Its durable design ensures up to 30 mating cycles, suitable for precise electronic applications requiring reliable flat flexible cable connections.
MOLEX 39532095 FFC/FPC Connector Specifications:
- Pitch - Mating Interface: 1.25mm
- Number of Circuits (Loaded): 9
- Number of Circuits (Maximum): 9
- Color - Resin: Natural
- Actuator Type: Slider
- Durability (Mating Cycles Max): 30
- Flammability: 94V-0
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin-Bismuth
- Material - Plating Termination: Tin-Bismuth
- Material - Resin: Polyester
- Maximum Current per Contact: 1.0A
- Maximum Voltage: 200V
- Operating Temperature Range: -20°C to +80°C
- Mated Height: 7.50mm
- PCB Tail Length: 3.50mm
- Packaging Type: Tray
- Surface Mount Compatible: No
- Orientation: Vertical
- Stackable: No
- RoHS and REACH compliant, UL certified, halogen-free
Buy the Buy Molex FFC-FPC Connector Part Number 0039532095 Online
Purchase the Molex FFC-FPC connector with 1.25mm pitch and 9 circuits online today. This vertical ZIF connector offers reliable connections for flexible flat cables, with high durability of 30 mating cycles. Made from high-quality phosphor bronze with tin-bismuth plating, it is UL, RoHS, and REACH compliant, suitable for applications requiring stable electrical performance from -20°C to +80°C. Easy to install and ideal for compact electronic assemblies, order now for quick delivery and superior connection performance.
Buy Molex 0039532095 now and experience unmatched reliability and performance for your electronic connector needs, ensuring secure and durable FFC/FPC connections.
Frequently Asked Questions
Where can I buy MOLEX 39532095?
You can click on the BUY or RFQ button to purchase 39532095 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 39532095?
You can download the 39532095 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 39532095?
MOLEX
