MOLEX 431604302 Power Connector
The Sabre Power Connector features a 7.50mm pitch with a vertical 2-circuit design, glow-wire capability, PCB thickness support of 2.40mm, and a rugged black resin. Made from brass with tin plating and a high-temperature thermoplastic housing, it provides reliable electrical performance with a maximum current of 18A and voltage up to 600V. Suitable for high-power wire-to-board applications, it ensures safety with UL and CSA certifications, a durability of up to 25 mating cycles, and compatibility with various PCB configurations for industrial and electronic applications.
MOLEX 431604302 Power Connector Specifications:
- Pitch: 7.50mm to mating interface, 7.50mm to termination interface
- Number of circuits: 2
- Color: Black
- Material - Metal: Brass
- Plating - Metal: Tin
- Material - Resin: High Temperature Thermoplastic
- Flammability: 94V-0
- Current - Max: 18A
- Voltage - Max: 600V
- Operating temperature range: -40°C to +75°C
- PCB thickness: 2.40mm recommended
- Mating cycles: up to 25
- Locking: Board lock included
- Mounting orientation: Vertical
- Physical dimensions: Length approximately 5.33mm for PCB tail, overall design supports PCB retention and locator features
- Certification: UL Listed, CSA Certified
- Packaging: Tray
- Glow-wire capability: Yes, Glow Wire Ignition Temperature of at least 775°C per IEC 60695-2-13, GWFI above 850°C per IEC 60695-2-12
Buy the Molex 0431604302 – Reliable Power Connector for Industrial Applications
Enhance your electrical setups with the reliable Molex Power Connector designed for high-current power distribution in industrial, electronic, and control projects. Featuring a 7.50mm pitch, glow-wire capabilities, and UL certification, this 2-circuit connector offers durability, safety, and ease of installation. Made from high-temperature thermoplastic with tin-plated brass contacts, it supports up to 18A at 600V. Ideal for PCB assembly, it provides secure locking, multiple mating cycles, and consistent performance in demanding environments. Purchase online today and safeguard your projects with confidence.
Order your Molex Series0431604302 high-power connector today and ensure your power systems are safe, reliable, and ready for demanding industrial environments.
