MOLEX 439141104 Power Receptacle Housing
This is a Mini-Fit Sr. Power Receptacle housing with a 10.00mm pitch, designed for power, wire-to-board, and wire-to-wire applications. It features a dual-row configuration with 12 circuits, made from black polyester resin. The connector meets UL and CSA certifications, is RoHS and REACH compliant, and supports operating temperatures from -40°C to +105°C. Designed for high current capacity of up to 50A per circuit, it is suitable for industrial power and electronic systems requiring robust and reliable power interfaces. The housing ensures safe and secure electrical connections with easy panel mounting options.
MOLEX 439141104 Power Receptacle Housing Specifications:
- Pitch - Mating Interface: 10.00 mm
- Number of Circuits: 12
- Color - Resin: Black
- Flammability: UL 94V-0
- Material - Resin: Polyester
- Temperature Range - Operating: -40°C to +105°C
- Current - Maximum per Contact: 50A
- Gender: Receptacle
- Packaging Type: Bag
- RoHS Compliance: Yes
- UL/CSA Certified: Yes
- Glow-Wire Capable: No
- Stackable: No
- Net Weight: 18.709 g
- Physical: Suitable for Panel Mount, with dual-row configuration
Buy the Buy Molex Mini-Fit Sr. Power Receptacle Housing Part Number 439141104 Online
Discover the Molex Mini-Fit Sr. Power Receptacle housing, featuring a 10mm pitch, dual-row, 12 circuits, made from black polyester resin. Designed for high-current applications up to 50A, it offers UL and CSA certification, RoHS compliance, and operates from -40°C to +105°C. Its robust design ensures safe, reliable power connections in industrial, electronic, and power distribution systems. Easy to mount, it provides secure electrical connections for demanding power and wiring solutions. Order online now for fast delivery and trusted quality.
Buy Molex 439141104 now and experience unmatched reliability and high current capacity for industrial power applications, ensuring secure and durable connections.
Frequently Asked Questions
Where can I buy MOLEX 439141104?
You can click on the BUY or RFQ button to purchase 439141104 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 439141104?
You can download the 439141104 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 439141104?
MOLEX
