MOLEX 436501012 Micro-Fit 3.0 Header
The Molex 43650-1012 Micro-Fit 3.0 Right-Angle Header is a robust connector solution for wire-to-board applications. Designed with a 3.00mm pitch and a single-row configuration, this header accommodates 10 circuits and features a right-angle orientation for space-saving designs. The tin plating on both mating and termination interfaces ensures excellent solderability and corrosion resistance. It is glow-wire capable and compliant with international safety standards like IEC 60335-1, making it suitable for household and similar electrical appliances. The header's robust construction and reliable electrical performance make it ideal for a wide range of industrial and consumer electronics applications.
MOLEX 436501012 Micro-Fit 3.0 Header Specifications:
- Product Family: PCB Headers
- Application: Power, Wire-to-Board
- Circuits (Loaded): 10
- Circuits (maximum): 10
- Color - Resin: Black
- Durability (mating cycles max): 30
- Flammability: 94V-0
- Glow-Wire Capable: Yes
- Mated Height: 6.98mm
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Net Weight: 1.593/g
- Number of Rows: 1
- Orientation: Right Angle
- PCB Locator: Yes
- PCB Retention: Yes
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Embossed Tape on Reel
- Pitch - Mating Interface: 3.00mm
- Plating min - Mating: 2.540µm
- Plating min - Termination: 2.540µm
- Polarized to PCB: Yes
- Shrouded: Fully
- Stackable: No
- Temperature Range - Operating: -40° to +105°C
- Termination Interface Style: Surface Mount
- Current - Maximum per Contact: 8.5A
- Voltage - Maximum: 600V
- Duration at Max Process Temperature: 030 seconds
- Lead-free Process Capability: REFLOW
- Max Cycles at Max Process Temperature: 003
- Process Temperature max C: 260°C
