MOLEX 444280402 Micro-Fit Connector
The Micro-Fit 3.0 connector system features a dual-row, right-angle header with surface mount compatibility, snap-in plastic PCB lock, and gold-plated contacts. Designed for high-temperature applications, it supports up to 8.5A per contact and 600V. Its durable design ensures up to 30 mating cycles, with a compact 3.50mm pitch and 1.60mm PCB tail length. Certified CSA and UL, it is RoHS and REACH compliant, suitable for board-to-board, wire-to-board, and power connections in demanding industrial and electronic systems.
MOLEX 444280402 Micro-Fit Connector Specifications:
- Number of Circuits: 4
- Color - Resin: Black
- Flammability: 94V-0
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Pin Pitch: 3.50mm
- PCB Tail Length: 1.60mm
- Operating Temperature Range: -40°C to +105°C
- Maximum Current per Contact: 8.5A
- Maximum Voltage: 600V
- Durability (mating cycles max): 30
- Surface Mount Compatibility: Yes
- Packaged as: Tray
- Lock type: Snap-in Plastic Peg PCB Lock
- Certification: CSA, UL
- RoHS, REACH Compliant
- Process Temperature Max: 260°C
- Material - Resin: High Temperature Thermoplastic
Buy the Molex 444280402 – Reliable Micro-Fit 3.0 Connector for Industrial Applications
Experience the reliability and high performance of the Molex Micro-Fit 3.0 connector series. With a dual-row, right-angle design, and surface mount compatibility, it delivers up to 8.5A and 600V for demanding industrial and electronic applications. Its gold-plated contacts ensure optimal conductivity and durability. Certified CSA and UL, RoHS compliant, and capable of withstanding up to 30 mating cycles, this connector is ideal for power and board-to-board systems in tough environments. Order online now for quick delivery and trusted quality.
Order your Molex Series Micro-Fit 3.0 444280402 connector today and ensure dependable, high-current connections in your industrial projects.
Frequently Asked Questions
Where can I buy MOLEX 444280402?
You can click on the BUY or RFQ button to purchase 444280402 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 444280402?
You can download the 444280402 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 444280402?
MOLEX
