MOLEX 469920820 Mini-Fit Versa Color Receptacle
The MOLEX 46992-0820 Mini-Fit Versa Color Receptacle Housing is a robust and reliable connector solution for various power applications. This dual-row housing, molded from Nylon 6/6, offers excellent insulation and durability. Its red color provides visual differentiation, and the glow-wire capability ensures compliance with specific safety standards. Designed for wire-to-board and wire-to-wire connections, it is a key component in numerous industrial and consumer electronic devices. The receptacle is compatible with Mini-Fit Versa Color Plug and Header series, facilitating easy integration into existing systems.
MOLEX 469920820 Mini-Fit Versa Color Receptacle Specifications:
- Product Family: Crimp Housings
- Series: 46992
- Application: Power, Wire-to-Board, Wire-to-Wire
- Circuits (maximum): 8
- Color - Resin: Red
- Gender: Receptacle
- Glow-Wire Capable: Yes
- Keying to Mating Part: None
- Lock to Mating Part: Yes
- Material - Resin: Nylon
- Net Weight: 1.740/g
- Number of Rows: 2
- Packaging Type: Bag
- Panel Mount: No
- Pitch - Mating Interface: 4.20mm
- Pitch - Termination Interface: 4.20mm
- Polarized to Mating Part: Yes
- Temperature Range - Operating: -40° to +105°C
- UPC: 195842021884
- Mates With: Mini-Fit Versa Color Plug 46993, Mini-Fit Versa Color Header 172447
- Use With: Mini-Fit Female Crimp Terminal 5556
- EU ELV: Not Relevant
- EU RoHS: Compliant
- China RoHS: Not Contained Per - D(2020)4578-DC
- Halogen-Free Status: Not Low-Halogen
- RoHS Phthalates: Not Contained
Buy the 46992-0820 MOLEX Mini-Fit Versa Color Receptacle | myMectronic
Purchase the MOLEX 46992-0820 Mini-Fit Versa Color Receptacle Housing securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 469920820?
You can click on the BUY or RFQ button to purchase 469920820 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 469920820?
You can download the 469920820 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 469920820?
MOLEX
