MOLEX 471554001 Serial ATA Connector

The Serial ATA high-speed connector features a 1.27mm pitch with a vertical through-hole design, locking latch, and 7 circuits. Constructed with durable brass and gold plating for reliable electrical connections, it supports up to 500 mating cycles. Designed for PCB applications with a 1.60mm thickness, it includes PCB locator pegs and retention features. Operating reliably from -35°C to +85°C, this connector ensures secure, EMI-resistant connections in high-speed data transfer environments, suitable for board-to-board and wire-to-board configurations, integrating seamlessly with SATA drives and devices.

View 471554001Datasheet [pdf]

Buy the Molex Series 47155 Serial ATA High Speed Header: 47155-4001

Buy Molex 47155-4001 online—designed for high-speed serial ATA connections, this connector offers a 1.27mm pitch, 7 circuits, and a locking latch for secure, high-reliability data transfer. Crafted from durable brass with gold plating, it supports up to 500 mating cycles and operates across -35°C to +85°C temperatures. Suitable for PCB and wire-to-board applications, it features PCB locator pegs, retention clips, and a vertical through-hole design, ensuring seamless integration with modern SATA drives and electronic devices for dependable performance.

Get Molex 47155-4001 today—built for high-speed data transfer and reliable connections in PCB and device applications.
