MOLEX 5055750671 Wire-to-Board Connector
The Micro-Lock PLUS Vertical Header with a 2.00mm pitch is designed for reliable wire-to-board connections, featuring matte tin plating and a compact single-row configuration with six circuits. Manufactured with durable materials, it supports up to 30 mating cycles, ensuring long-lasting performance. Suitable for applications requiring a maximum current of 3.0A and voltage of 250V AC/DC, this connector is ideal for various electronic devices. Its robust construction and precise engineering enable secure and efficient connections in tight spaces, making it a versatile solution for modern electronic assemblies.
MOLEX 5055750671 Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 2.00mm
- Number of Circuits: 6
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Matte Tin
- Material - Plating Termination: Matte Tin
- Temperature Range - Operating: -40°C to +105°C
- Durability (mating cycles max): 30
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V AC/DC
- Net Weight: 720.380 mg
- Packaging: Embossed Tape on Reel
- Orientation: Vertical
- Lock to Mating Part: Yes
- Guides to Mating Part: Yes
- Polarized to Mating Part: Yes
- Polarized to PCB: No
- Stackable: No
Buy the Molex Series Micro-Lock Plus 2.00mm Pitch Vertical Header: 5055750671
Enhance your electronic assemblies with the Molex Series Micro-Lock Plus Vertical Header featuring a 2.00mm pitch and six circuits. Made with durable brass material and matte tin plating, this connector offers reliable wire-to-board connections for various applications. It supports up to 30 mating cycles, with a maximum current of 3.0A and voltage of 250V AC/DC, ensuring safe and efficient performance. Ideal for compact, high-precision electronic devices, this connector ensures secure connections in tight spaces, providing long-lasting reliability for your projects.
Order your Molex Series Micro-Lock Plus 2.00mm Pitch Vertical Header today and give your electronic projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy MOLEX 5055750671?
You can click on the BUY or RFQ button to purchase 5055750671 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5055750671?
You can download the 5055750671 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5055750671?
MOLEX
