MOLEX 705530116 Signal Connector
The SL Modular Connectors series features 2.54mm pitch low-profile, right-angle headers with 12 circuits, gold and tin plating, capable of supporting 3A current per contact, operating up to 105°C. Designed for signal and wiring applications, these PCB headers are durable with 50 mating cycles and comply with RoHS and halogen-free standards. They are suitable for use in signal, wire-to-board connections, and are compatible with various mating connectors, providing reliable and secure connections in electronic assemblies.
MOLEX 705530116 Signal Connector Specifications:
- Pitch: 2.54mm
- Number of Circuits: 12
- Material - Metal: Brass, Phosphor Bronze
- Plating - Mating: 0.762um Gold
- Plating - Termination: 1.905um Tin
- Operating Temperature: -40°C to +105°C
- Current per Contact: 3.0A
- Voltage Maximum: 250V
- Durability (Mating Cycles): 50
- Flammability: 94V-0
- Color - Resin: Black
- Orientation: Right Angle
- PC Tail Length: 3.30mm
- Material - Resin: High Temperature Thermoplastic
- Locking: Yes, Lock to Mating Part
- Guide to Mating Part: Yes
- Package: Tube
Buy the Buy Molex Signal Connector Part Number 705530116 Online
Order the Molex signal connector 705530116 online today for your electronic projects. This high-quality PCB header features 12 circuits, gold and tin plating, supporting 3A current, and operates safely up to 105°C. Perfect for signal, wire-to-board applications, it offers reliable connection with up to 50 mating cycles. Its durable construction meets RoHS and halogen-free standards, ensuring compliance and safety. Easy to install and universally compatible, this connector is ideal for industrial, automation, and electronics manufacturing needs.
Get Molex 705530116 today—robust 2.54mm pitch PCB header designed for high reliability in signal and wire-to-board connections.
Frequently Asked Questions
Where can I buy MOLEX 705530116?
You can click on the BUY or RFQ button to purchase 705530116 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 705530116?
You can download the 705530116 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 705530116?
MOLEX
