MOLEX 877580416 Milli-Grid Connector
The Milli-Grid connector system features a 2.00mm pitch header with through-hole, vertical mounting, and 4 circuits. It offers 0.38 micrometer gold selective plating, is lead-free, and packaged in pockets or trays. Designed for reliable board-to-board connections, this high-performance header supports up to 2A current per contact and 125V maximum voltage. Constructed from durable nylon with phosphor bronze contacts, it adheres to UL and RoHS standards, making it suitable for a wide range of industrial and electronic applications requiring high mating cycles and environmental compliance.
MOLEX 877580416 Milli-Grid Connector Specifications:
- Pitch: 2.00mm
- Number of Circuits: 4
- Color - Resin: Black
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Temperature Range - Operating: -55°C to +105°C
- Current per Contact: 2A
- Voltage Maximum: 125V
- Durability (mating cycles max): 100
- Flammability: 94V-0
- Process Temperature max: 250°C
- Packaging: Pocket Tray
- Connector Type: Board-to-Board, Signal
- Mounting Style: Through Hole
- Orientation: Vertical
- Mated Height: 2.60mm
- Surface Mount Compatibility (SMC): No
- RoHS compliant: Yes
- UL certified: Yes
- Weight: 0.101 grams per unit
Buy the Buy Molex Milli-Grid Connector Part Number 87758-0416 Online
Secure your electronic assemblies efficiently with the Milli-Grid Connector system. Featuring a 2.00mm pitch, four circuits, and gold-plated contacts, it ensures reliable signal transfer and durability. This UL and RoHS-compliant product is designed for high mating cycles, operating in temperatures from -55°C to +105°C, with current capacity of 2A per contact. Packaged in trays for easy handling, it’s ideal for industrial applications requiring robust, lead-free connectors that provide excellent environmental compliance and long-term performance.
Buy Molex 87758-0416 now and experience unmatched reliability and high-performance board-to-board connections with durable gold-plated contacts.
Frequently Asked Questions
Where can I buy MOLEX 877580416?
You can click on the BUY or RFQ button to purchase 877580416 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 877580416?
You can download the 877580416 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 877580416?
MOLEX
