MOLEX 878335020 Milli-Grid Connector
The Milli-Grid Header is a reliable, lead-free, right-angle connector with 50 circuits, gold-plated contacts, and shrouded design for secure wire-to-board connections. It features a center polarization slot, locking windows, and nylon housing, supporting a temperature range from -55°C to +105°C. Designed for applications requiring high durability and safety, it offers a maximum current of 2.0A per contact and a maximum voltage of 125V. Compatible with various Milli-Grid receptacles, it ensures secure, efficient, and compliant connections in industrial and automotive projects, providing high-performance electrical connectivity.
MOLEX 878335020 Milli-Grid Connector Specifications:
- Number of Circuits: 50
- Contact Material: Phosphor Bronze
- Plating Mating: Gold
- Material - Resin: Nylon
- Operating Temperature Range: -55°C to +105°C
- Maximum Current per Contact: 2.0A
- Maximum Voltage: 125V
- Termination Interface: Through Hole
- Pitch - Mating Interface: 2.16mm
- PC Tail Length: 1.60mm
- Color - Resin: Not specified
- Flammability: UL 94V-0
- RoHS Compliance: Yes, Lead-Free
- Durability (Mating Cycles Max): Not specified
- Net Weight: 2.546g
- Stackable: No
- Shrouded: Yes
- Guide to Mating Part: Milli-Grid Vertical Through Hole Receptacle
- Keying to Mating Part: Center Polarization Slot
- PCB Thickness - Recommended: 1.60mm
- PCB Retention: Yes
- Surface Mount Compatible: No
- Package Type: Tube
Buy the Molex Series Milli-Grid Connector: 878335020
Secure your electrical connections with the high-performance Milli-Grid Connector that features 50 circuits, gold-plated contacts, and a shrouded right-angle design. Crafted from durable nylon and offering a temperature range from -55°C to +105°C, it ensures safe, reliable operation in demanding industrial and automotive environments. With a maximum current of 2.0A per contact and compliance with RoHS standards, this connector is ideal for applications requiring high durability, precise polarization, and secure mating. Order online now to enhance your project's connection integrity and efficiency.
Order your Molex Series Milli-Grid 878335020 connector today and secure high-quality, reliable wire-to-board electrical connections for your projects.
Frequently Asked Questions
Where can I buy MOLEX 878335020?
You can click on the BUY or RFQ button to purchase 878335020 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 878335020?
You can download the 878335020 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 878335020?
MOLEX
