MOLEX 901301134 Signal Connector
The C-Grid III Header is a high-quality signal wire-to-board connector featuring a dual-row, vertical, shrouded design with 34 circuits. It is constructed with durable brass and plated with tin over nickel, ensuring reliable connections. The connector supports up to 30 mating cycles and withstands operating temperatures from -55°C to +125°C. Its 2.54mm pitch and through-hole termination make it suitable for PCB mounting. Compliant with RoHS and UL standards, the C-Grid III is ideal for applications requiring robust, vibration-resistant connections in industrial and electronic devices.
MOLEX 901301134 Signal Connector Specifications:
- Number of Circuits: 34
- Color: Black
- Material - Metal: Brass
- Material - Plating: Tin over Nickel (mating and termination)
- Material - Resin: Polyester
- Flammability: 94V-0
- Durability: 30 mating cycles
- Operating Temperature: -55°C to +125°C
- Voltage Rating: 350V AC/DC
- Current per Contact: 3.0A
- Pitch - Mating Interface: 2.54mm
- Guide to Mating Part No: 90142 C-Grid III Crimp Housing
- PCB Thickness - Recommended: 1.60mm
- Terminations: Through Hole
- Physical Dimension: PC Tail Length 2.90mm
- Shrouded Ends: Closed
- Lock to Mating Part: Yes
- Stackable: No
- RoHS Compliant: Yes
- Agency Certifications: UL, CSA
Buy the Molex 901301134 – Reliable Signal Connectors for Industrial Applications
Enhance your electronic systems with the Molex C-Grid III connector, offering reliable 34-circuit signal connections in a durable, RoHS-compliant, dual-row design. This high-quality wire-to-board connector features a 2.54mm pitch, through-hole termination, and a temperature range of -55°C to +125°C, making it suitable for industrial, automation, and electronic applications. Its sturdy brass construction with tin over nickel plating ensures long-lasting performance, up to 30 mating cycles, providing excellent vibration resistance and dependable performance in diverse environments.
Order your Molex 901301134 Series C-Grid III Connector today and secure a robust, high-quality connection solution for your industrial and electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 901301134?
You can click on the BUY or RFQ button to purchase 901301134 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901301134?
You can download the 901301134 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901301134?
MOLEX
