MOLEX 901471206 C-Grid Connector
The C-Grid PC Board Connector from Molex is a robust single-row, vertical connector featuring 6 circuits with gold plating for enhanced conductivity and corrosion resistance. Designed for reliable board-to-board connections, it supports up to 6 circuits with a maximum current of 3A per contact and a maximum voltage of 350V. Crafted from phosphor bronze with gold plating, it ensures optimal electrical performance and durability. Suitable for applications requiring secure, multi-circuit connections with a compact design, this connector adheres to industry standards and RoHS compliance, offering a dependable solution for electronic assemblies.
MOLEX 901471206 C-Grid Connector Specifications:
- Number of Circuits: 6
- Maximum Circuits: 6
- Color - Resin: Black
- Durability (mating cycles max): 100
- Flammability: 94V-0
- Guide to Mating Part: None
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 0.516 grams
- Number of Rows: 1
- Orientation: Vertical
- PC Tail Length: 2.90mm
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 2.54mm
- Plating min - Mating: 0.381 micrometers
- Plating min - Termination: 3.048 micrometers
- Temperature Range - Operating: -55°C to +125°C
- Current - Maximum per Contact: 3A
- Voltage - Maximum: 350V
- Termination Interface: Style: Through Hole
- Process Temperature max.: 230°C
- Process Duration at Max Temp.: Data not specified
Buy the Buy Molex C-Grid Connector Part Number 0901471206 Online
Enhance your electronic assemblies with the Molex C-Grid connector, featuring 6 circuits, gold plating for corrosion resistance, and vertical orientation for space-efficient PCB mounting. Its durable construction supports up to 100 mating cycles, ensuring long-term performance. With RoHS compliance and industry certifications, this connector meets safety and environmental standards. Easy to install and compatible with various boards, it delivers secure, reliable electrical connections for industrial, consumer electronics, and other applications that demand high quality and dependability.
Buy Molex 0901471206 now and experience unmatched reliability and high-performance PCB connections.
Frequently Asked Questions
Where can I buy MOLEX 901471206?
You can click on the BUY or RFQ button to purchase 901471206 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901471206?
You can download the 901471206 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901471206?
MOLEX
