MOLEX 99990990 Wire-to-Board Connector
The Mini-SPOX Wire-to-Board Connector System features a 2.50mm pitch and offers reliable signal transfer with six circuits, tin-plated for corrosion resistance. Designed for vertical, shrouded mounting, it provides up to 6 circuits with durable nylon housing capable of withstanding up to 30 mating cycles. Rated for -40°C to +105°C, it supports a maximum voltage of 250V and a current of 3.0A per contact. Its compact design includes PC tails, PCB retention features, and polarization for secure mating in various electronic applications.
MOLEX 99990990 Wire-to-Board Connector Specifications:
- Pitch: 2.50mm
- Number of Circuits: 6
- Max Voltage: 250V
- Max Current per Contact: 3.0A
- Material - Housing: Nylon
- Plating - Mating: Tin
- Plating - Termination: Tin
- Temperature Range: -40°C to +105°C
- Durability: Up to 30 mating cycles
- Orientation: Vertical
- PC Tail Length: 3.50mm
- PCB Thickness - Recommended: 1.60mm
- Flammability Rating: UL 94V-0
- Color: Natural
- Shrouded: Yes
- Stackable: No
- Surface Mount Compatible: No
- Termination Interface: None
- RoHS Compliant: Yes
- UL and CSA Certified
- Application: Wire-to-Board connections in electronic devices
Buy the Molex Series Mini-SPOX Wire-to-Board Connector 2.50mm: 0099990990
Purchase the Molex Mini-SPOX Wire-to-Board Connector featuring a compact 2.50mm pitch, six circuits, and durable nylon construction. Its tin-plated contacts ensure corrosion resistance and reliable connectivity for various electronic devices. Rated for operating temperatures from -40°C to +105°C, it supports up to 250V and 3A per contact, making it ideal for demanding applications. With a vertical orientation and lock features, this shrouded connector offers secure, high-quality connections, perfect for DIY projects, manufacturing, or repair tasks involving electronic assemblies.
Buy Molex 0099990990 now and experience unmatched reliability and performance with durable, tin-plated contacts designed for demanding electronic applications.
Frequently Asked Questions
Where can I buy MOLEX 99990990?
You can click on the BUY or RFQ button to purchase 99990990 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 99990990?
You can download the 99990990 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 99990990?
MOLEX
