MULTICOMP PRO 7030109 Green SMD LED
This green surface-mount device LED features a white diffused lens with GaP/GaP material, delivering reliable illumination for electronic circuits. It boasts a power dissipation of 78mW, a wide viewing angle of 140°, and a luminous intensity of 11mcd. Operating safely within -40°C to +80°C, it supports a forward voltage of 1.9V to 2.6V at 20mA. Ideal for LED indicator, display, or illumination applications, it complies with RoHS standards and is recommended for reflow soldering at 260°C for up to 10 seconds, ensuring durability and consistent performance.
MULTICOMP PRO 7030109 Green SMD LED Specifications:
- Material: GaP / GaP
- Emitting Color: Green
- Lens Color: White diffused
- Power Dissipation: 78mW
- Luminous Intensity: 11mcd
- Forward Voltage: 1.9V to 2.6V at 20mA
- Viewing Angle: 140°
- Peak Wavelength: 567nm
- Operating Temperature Range: -40°C to +80°C
- Storage Temperature Range: -40°C to +85°C
- Soldering Temperature: 260°C for 10 seconds
- Mechanical Dimensions: 2.0 mm x 1.0 mm x 0.6 mm
- RoHS Compliant
Buy the Multicomp Series Green LED: 7030109
Choose the Multicomp Series Green SMD LED with white diffused lens for your electronic projects. This GaP/GaP device delivers bright, reliable illumination with an 11mcd luminous intensity and 140° viewing angle. Its compact size and RoHS compliance make it perfect for indicator lights, displays, and general LED lighting. Designed for easy reflow soldering at 260°C for 10 seconds, it ensures excellent performance and durability. Order online now to enhance your electronic designs with high-quality, energy-efficient LED components.
Get Multicomp Series 7030109 today—built for high brightness and long-lasting durability in LED lighting.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 7030109?
You can click on the BUY or RFQ button to purchase 7030109 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 7030109?
You can download the 7030109 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 7030109?
MULTICOMP PRO
