MULTICOMP PRO HC49S2450506030ATF Crystal Oscillator
This high-quality crystal oscillator is designed for applications requiring precise timing and frequency stability. Featuring a low profile, surface-mount design, it suits space-constrained environments such as microcontrollers and communication equipment. It offers a frequency range of 3.5 to 32 MHz, with tight tolerance of +20, +30, or +50 ppm at 25°C, and a temperature stability of +30 or +50 ppm. The crystal has an operating temperature of -10°C to +60°C, a maximum drive level of 200μW, and an insulation resistance of 500MΩ, ensuring reliable operation in industrial settings.
MULTICOMP PRO HC49S2450506030ATF Crystal Oscillator Specifications:
- Nominal Frequency Range: 3.5 to 32 MHz
- Vibration Mode: Fundamental (AT), 3rd Overtone (AT)
- Frequency Tolerance at 25°C: +20, +30, or +50 ppm
- Temperature Stability: +30 or +50 ppm
- Operating Temperature Range: -10°C to +60°C
- Storage Temperature Range: -20°C to +70°C
- Load Capacitance: 8 pF to 32 pF or series
- Equivalent Series Resistance: See ESR table
- Shunt Capacitance: 5pF maximum at 18 MHz or 7pF above 18 MHz
- Drive Level: 200μW maximum (<5 MHz), 100μW maximum (>5 MHz)
- Insulation Resistance: 500MΩ minimum at 100V DC
- Aging: +5 ppm per year
Buy the Multicomp Reliable 3.5–32 MHz Crystal for Industrial Applications
Purchase the Multicomp crystal oscillator online today to ensure your projects benefit from high accuracy, durability, and space-saving design. It is perfect for clocks, microcontrollers, and communication systems requiring stable frequency performance. Available in a compact, surface-mount package, it simplifies assembly and saves board space. With a frequency range of 3.5 to 32 MHz and tight tolerance options, this product guarantees reliable operation in industrial environments. Order now to enhance your electronic designs with this precision component.
Get Multicomp crystal oscillator today—built for precision and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49S2450506030ATF?
You can click on the BUY or RFQ button to purchase HC49S2450506030ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49S2450506030ATF?
You can download the HC49S2450506030ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49S2450506030ATF?
MULTICOMP PRO
