MULTICOMP PRO MCKSD380D5W037 Solid State Relay
This high-quality solid state relay from Multicomp Pro is designed for industrial applications including lighting, motor control, and medical devices. It supports load voltages from 124 to 440V AC and a control voltage range of 4-32V DC. Featuring zero crossing switching and opto-isolation of 4000VACrms, it ensures safe and reliable operation with high inrush current capability. Its compact plastic case weighs 120 grams and operates efficiently within -30°C to +80°C ambient temperature. Ideal for automation systems requiring fast switching and durability, this relay provides a switching current of up to 5A for reliable performance.
MULTICOMP PRO MCKSD380D5W037 Solid State Relay Specifications:
- Control Voltage Range: 4V DC to 32V DC
- Min. Turn-On Voltage: 4V DC
- Min. Turn-Off Voltage: 1V DC
- Max. Input Current: 25mA
- Load Voltage Range: 124 ~440V AC
- Transient Over Voltage: 800Vpk
- Load Current Range: 0.1~5A
- Max. Turn-On Time: 10ms
- Zero Crossing: Yes
- Max. Turn-off Time: 10ms
- Max. Surge Current (@10 ms): 250A
- Max. Off-State Leakage Current: 1.5mA
- Max. On-State Voltage Drop: 1.5Vrms
- Max. Off-State dv/dt: 500V/us
- Dielectric Strength Input/Output: 24000Vrms
- Ambient Operating Temperature Range: -30°C to +80°C
- Ambient Storage Temperature Range: -30°C to +100°C
- Weight: 120g
Buy the Buy Multicomp Solid State Relay Part Number MCKSD380D5W037 Online
Purchase the Multicomp Pro solid state relay MCKSD380D5W037 online for reliable industrial performance. With support for load voltages up to 440V AC and a control voltage of 4-32V DC, it is ideal for lighting, motor control, and medical applications. Its zero crossing switching minimizes electrical noise, and the opto-isolation of 4000VACrms ensures safety. Compact and durable, this relay supports 5A current, quick switching times, and operates effectively within -30°C to +80°C environments. Buy online today for seamless integration into your automation systems.
Get Multicomp Pro solid state relay MCKSD380D5W037 today—designed for industrial automation with high inrush current capability and zero crossing switching.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCKSD380D5W037?
You can click on the BUY or RFQ button to purchase MCKSD380D5W037 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCKSD380D5W037?
You can download the MCKSD380D5W037 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCKSD380D5W037?
MULTICOMP PRO
