MULTICOMP PRO PP002738 heat shrink tubing
The 2:1 normal wall heat shrink tubing provides reliable insulation and mechanical protection for wires and components. Manufactured from radiation cross-linked polyolefin, it is halogen-free, flexible, and shrinks at lower temperatures. Operating between -55°C and +125°C, it offers good electrical and mechanical performance, including tensile strength up to 210.4 MPa, elongation of 2200%, and dielectric strength of 215 kV/mm. Available in multiple colors and sizes, it is suitable for electrical insulation, wire harnessing, and protection in temperature-sensitive environments.
MULTICOMP PRO PP002738 heat shrink tubing Specifications:
- Shrink Ratio: 2:1
- Operating Temperature: -55°C to +125°C
- Min. Shrink Temperature: 70°C
- Full Recovery Temperature: 120°C
- Tensile Strength: 210.4 MPa
- Ultimate Elongation: 2200%
- Dielectric Strength: 215 kV/mm
- Volume Resistivity: 21x10^4 Ω·cm
- Flammability: Meets FMVSS302
- Color options: Black, Brown, Blue, White, Red, Yellow, Green, Grey, Yellow/Yellow, Clear
- Dimensions (example size 3/8 inch): Internal diameter before shrink 9.5 mm, after recovery 45 mm, wall thickness 0.3 mm
- Shrink Temperature: 70°C to 120°C
- Material: Cross-linked polyolefin
- Suitable applications: Wire insulation, cable protection, electrical insulation, temperature-sensitive component protection
Buy the Pro-Power Series 2:1 Heatshrink Tubing: PP002738
Discover the high-quality Pro-Power Series heat shrink tubing, offering excellent insulation, flexibility, and environmental resistance. Designed for electrical insulation, wire harnessing, and cable protection, this tubing shrinks at lower temperatures, making it safe for temperature-sensitive components. Its durable, cross-linked polyolefin construction ensures long-lasting mechanical and electrical performance across a wide temperature range from -55°C to +125°C. Suitable for various industrial applications, it comes in multiple sizes and colors, providing versatile solutions for your electrical and mechanical protection needs.
Order your Pro-Power Series 2:1 heatshrink tubing today and ensure your projects benefit from reliable electrical insulation and mechanical protection.
Frequently Asked Questions
Where can I buy MULTICOMP PRO PP002738?
You can click on the BUY or RFQ button to purchase PP002738 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part PP002738?
You can download the PP002738 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of PP002738?
MULTICOMP PRO
