NKK Switches ISL02A1C LCD Control Board
The logic board compatible with 64x32 RGB LCD displays features two switches, socket connections, and is designed for efficient control and integration in display systems. It allows easy mounting of LCD screens and switches directly or via sockets, supporting various configurations. The board includes essential connectors for communication with controllers and supports daisy-chaining multiple units. Compact and versatile, this PCB assembly enhances system flexibility, providing reliable operation for industrial or commercial display applications with stable electrical performance and a sturdy design.
NKK Switches ISL02A1C LCD Control Board Specifications:
- Compatible with 64x32 RGB LCD displays
- Supports two switches for control
- Includes socket connections for flexible mounting
- Daisy-chain capable via ribbon cable connectors
- Connector: 14-pin ribbon cable interface for controller connections
- Input port: 7x2 male header, 0.1 inch spacing
- Output port: 7x2 male header, 0.1 inch spacing
- Pin functions include GND, V+ (9V/5V), control signals (LP, FLM, SCP, VLC), and switch contacts
- Dimensions: compact PCB size, externally sourced external dimensions approximate 70mm x 28mm
- Material: standard PCB with electrical components rated for industrial use
- Electrical specifications support 9V or 5V operation depending on system setup
- Designed for easy installation and robust operation in embedded systems
Buy the NKK Switches Series LCD Control: ISL02A1C
Order the NKK Switches LCD Control Board ISL02A1C online today to enhance your display system integration. Featuring socket connections, support for two switches, and daisychaining capabilities, this PCB assembly offers flexible configuration options. Its compact design suits industrial environments, ensuring stable electrical performance and durability. Perfect for controlling 64x32 RGB LCD displays, the board simplifies mounting and wiring, providing reliable connection and operation. Purchase now to upgrade your display project with a trusted component designed for long-lasting performance and easy installation.
Get NKK Switches ISL02A1C today—built for reliable performance in LCD control systems with multiple switch integrations.
Frequently Asked Questions
Where can I buy NKK Switches ISL02A1C?
You can click on the BUY or RFQ button to purchase ISL02A1C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part ISL02A1C?
You can download the ISL02A1C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of ISL02A1C?
NKK Switches
