NKK Switches UB15NBKG015C Pushbutton Switch
A low-profile, illuminated pushbutton switch compatible with PCB mounting and solder connections. Designed for easy installation and reliable operation in various electronic applications.
NKK Switches UB15NBKG015C Pushbutton Switch Specifications:
- Poles & Circuits: Single Pole, SPDT
- Mounting Type: PCB Mounting, Snap-in
- LED Types & Colors: Bright and super bright LEDs in red, amber, green, white, blue; full face, spot illumination options
- Cap Types & Colors: Full face illuminated, spot, diffusers in polycarbonate, matte or glossy finishes
- Electrical Capacity: 5A @ 125/250V AC, 0.4VA max @ 28V AC/DC
- Contact Resistance: 50 milliohms max for silver, 100 milliohms max for gold
- Insulation Resistance: 200 megohms min at 500V DC
- Dielectric Strength: 1,000V AC contact-to-contact, 1,500V AC contact-to-case for 1 min
- Mechanical Life: 1,000,000 operations; Electrical Life: 200,000 operations
- Operating Temp Range: -25°C to +50°C for illuminated, -20°C to +70°C for non-illuminated
- Vibration & Shock: 10-55Hz, 50G shocks, 1.5mm vibration amplitude
- Housing Materials: UL94V-0 glass fiber reinforced polyamide, polycarbonate lens/diffuser
- Installation Force: 7.55N maximum, panel thickness 0.039” to 0.126”
- Soldering: Wave and manual soldering profiles in supplement
- Certifications: UL Recognized, CSA Certified (order markings required)
Buy the NKK Series UB Pushbutton Switch Part Number UB15NBKG015C
Get your NKK Series UB low-profile illuminated pushbutton switch online now. Featuring PCB mounting, solder terminals, multiple LED options, and certified reliability, it's ideal for compact electronic systems requiring durable and responsive controls. Designed for quick installation and long-lasting performance, this switch ensures reliable operation in demanding environments. Perfect for industrial automation, control panels, and user interfaces, it offers excellent electrical capacity and vibration resistance. Buy now to upgrade your project with proven quality and quick delivery.
Order your NKK Series UB pushbutton today and enhance your electronic controls with dependable performance and easy PCB mounting.
Frequently Asked Questions
Where can I buy NKK Switches UB15NBKG015C?
You can click on the BUY or RFQ button to purchase UB15NBKG015C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15NBKG015C?
You can download the UB15NBKG015C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15NBKG015C?
NKK Switches
