NKK Switches UB15SKW035CCC Low Profile Pushbutton Switch
This low-profile illuminated pushbutton switch features a compact design suitable for tight spaces and PCB mounting, with durable materials like polycarbonate and stainless steel. It offers bright LED illumination in various colors, including red, green, white, and amber, with different lens and diffuser options. The switch supports quick actuation with snap-acting contact mechanisms, ensuring a long electrical and mechanical life. Its compact size and robust construction make it ideal for control panels, industrial equipment, and electronic devices requiring reliable, easy-to-operate pushbutton functionality under diverse environmental conditions.
NKK Switches UB15SKW035CCC Low Profile Pushbutton Switch Specifications:
- Housing Material: Polycarbonate UL94V-0
- Base Material: GFR Polyamide
- LED Colors: Red, Amber, Green, White, Blue
- LED Forward Voltage: 1.85V to 3.2V
- Maximum Forward Current: 20-30mA
- Switch Rating: 5A @ 125/250V AC, 0.4VA @ 28V AC/DC
- Contact Resistance: Silver contacts 50 milliohms max, Gold contacts 100 milliohms max
- Insulation Resistance: 200 MΩ minimum @ 500V DC
- Dielectric Strength: 1,000V AC contact to case, 1-minute test
- Electrical Life: 200,000 operations for gold contacts
- Mechanical Life: 1,000,000 operations
- Nominal Operating Force: 1.9N for single-pole models
- Travel: Total 2.3mm (pretravel 1.7mm, overtravel 0.6mm)
- Operating Temperature: -20°C to +70°C, illuminated models -25°C to +50°C
- Vibration Resistance: 3 hours at 1.5mm amplitude, 10-55Hz
- Shock Resistance: 50G in 6 directions, 5 shocks each
- Panel Thickness: 1.0mm to 3.2mm
- Soldering: Wave or manual, profile A
- Approvals: UL Recognized, CSA Certified (when ordered accordingly)
Buy the Buy NKK Switches Low Profile Pushbutton Part Number UB15SKW035CCC Online
Discover the convenience of online purchasing for the NKK Switches Low Profile Pushbutton. Engineered for durability and quick actuation, this switch offers bright LED illumination, multiple color options, and long operational life—perfect for industrial controls, panel applications, and electronic devices. Easily installed in tight spaces with PCB mounting and snap-in options, it ensures reliable switching performance even under harsh environments. Order now to enhance your control systems with proven quality and efficient, hassle-free shopping experience.
Buy NKK Switches UB15SKW035CCC now and experience unmatched reliability and performance in compact control panels and electronic applications.
Frequently Asked Questions
Where can I buy NKK Switches UB15SKW035CCC?
You can click on the BUY or RFQ button to purchase UB15SKW035CCC from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15SKW035CCC?
You can download the UB15SKW035CCC datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15SKW035CCC?
NKK Switches
