NKK Switches YB216CWCKW016FJB Panel Switch
This round panel switch combines optical indication with reliable switching performance, featuring a super bright green LED with a clear lens and white diffuser. It supports SPDT operation with a 3A load at 125V AC. The switch is designed for easy mounting with solder lug and quick connect terminals, providing flexible wiring options. Its black bezel and compact design make it ideal for control panels needing clear circuit status indication and durability in industrial environments. Suitable for applications requiring clear visibility and robust operation.
NKK Switches YB216CWCKW016FJB Panel Switch Specifications:
- Poles & Circuits: Single Pole Double Throw
- Contact Point Shape: Round
- Switch Ratings: 3A at 125V AC, 3A at 250V AC, 0.4VA maximum at 28V AC/DC
- LED Indicator: Super Bright Green with Clear Lens and White Diffuser
- Terminals: Solder Lug and 0.110 inch quick connect
- Bezel: Black, with optional metallic silver
- Housing: Black
- Switch Base: UL94V-0 plastic
- Panel Thickness Range: 0.020 inch to 0.197 inch
- Mounting Torque: 0.785 Nm (6.95 lbf-in)
- Ambient Operating Temperature: -25°C to +50°C
- Protection Standards: IP65 IEC60529
- Dimensions: Approximate diameter 19.0 mm, height varies in assembly
Buy the Buy NKK YB2 Series YB216CWCKW016FJB Panel Seal Pushbutton Round Switch Online
Order the NKK YB2 Series Panel Switch today to enhance your control panel with a durable, easy-to-install switch featuring a super bright green LED indicator. Ideal for industrial environments, this SPDT switch supports 3A loads at 125V AC, providing clear circuit status with high visibility. Its versatile solder lug and quick connect terminals simplify wiring, while IP65 sealing ensures dust and water resistance. With a compact design and high durability, this switch delivers reliable performance for demanding applications. Secure your order online now for fast delivery and cost-effective solutions.
Buy NKK YB2 Series YB216CWCKW016FJB panel switch now and experience unmatched reliability and durable control performance in industrial applications.
Frequently Asked Questions
Where can I buy NKK Switches YB216CWCKW016FJB?
You can click on the BUY or RFQ button to purchase YB216CWCKW016FJB from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part YB216CWCKW016FJB?
You can download the YB216CWCKW016FJB datasheet or visit the NKK Switches website for support.
Who is the manufacturer of YB216CWCKW016FJB?
NKK Switches
