NKK Switches YB226CWSKW015F24FB DPDT toggle switch
This DPDT toggle switch features an ON-ON configuration with a black panel seal and bezel, rated for 3A at 125V AC. It includes solder lug and quick connect terminals for versatile panel mounting and reliable electrical performance, suitable for industrial and control panel applications. Constructed with durable materials and certified for safety, it offers durable operation with a mechanical life of 1,000,000 cycles. Its compact design saves behind-panel space, making it ideal for various electrical switching needs in demanding environments.
NKK Switches YB226CWSKW015F24FB DPDT toggle switch Specifications:
- Poles: Double Pole
- Contact Point Shape: Normally Open and Normally Closed
- Terminal Type: Solder Lug and Quick Connect
- Rated Current: 3A at 125V AC
- Rating: 3A at 125V AC, 3A at 250V AC, 0.4VA max. @ 28V AC/DC
- Material: Brass contacts with silver plating
- Panel Seal: IP65 standards (dust tight and splashproof)
- Switch Dimensions: 19.0mm diameter, with side-by-side mounting
- Operating Temperature Range: -25°C to +50°C
- Mechanical Life: 1,000,000 cycles
Buy the Buy NKK Switches DPDT Toggle Switch Part Number YB226CWSKW015F24FB Online
Purchase the NKK YB226CWSKW015F24FB toggle switch online today for your control panel needs. This reliable switch features a durable build, IP65 sealing, and versatile terminals—ideal for industrial environments. Its ON-ON configuration ensures consistent operation, while the silver-plated contacts provide low resistance and long life. With a compact design and high-quality materials, it delivers excellent electrical performance and mechanical durability, making it the perfect choice for demanding electrical switching applications. Order now and ensure seamless integration into your projects.
Buy NKK Switches YB226CWSKW015F24FB now and experience unmatched reliability and performance in electrical switching.
Frequently Asked Questions
Where can I buy NKK Switches YB226CWSKW015F24FB?
You can click on the BUY or RFQ button to purchase YB226CWSKW015F24FB from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part YB226CWSKW015F24FB?
You can download the YB226CWSKW015F24FB datasheet or visit the NKK Switches website for support.
Who is the manufacturer of YB226CWSKW015F24FB?
NKK Switches
