NXP SPC5775BDK3MME2 Automotive Microcontroller
The MPC5775E microcontroller is a high-performance automotive-grade device featuring advanced power management, multiple clock generation options, and extensive I/O capabilities including LVDS and CMOS interfaces. It offers precise electrical and thermal specifications, including robust ESD protection, configurable input/output characteristics, and a flexible oscillator circuit with external crystal support. The device is optimized for reliability in demanding automotive and industrial environments, supporting real-time processing, reliable data retention, and efficient power sequencing for complex control applications.
NXP SPC5775BDK3MME2 Automotive Microcontroller Specifications:
- Supply Voltage: 3.0 V to 4.0 V (ADC accuracy/linearity not guaranteed below 4.0 V)
- Maximum Input Current: 200 mA for all controller pins
- I/O Pad Current: GPIO pads typical 0.42 mA, peak rise/fall time 6-8 ns
- Oscillator Frequency Range: 8 to 40 MHz with crystal start-up time of 5 ms
- VEXTAL External Oscillator Voltage: 0.6 to 1.6 V
- Crystal Load Capacitance: 1.8 pF to 15.8 pF selectable via register
- PLL Lock Time: approximately 100-110 µs for PLL1 and PLL0
- Power Consumption (PLL Lock): Up to 75 mA in FINE LOCK state
- Temperature Range: Designed for automotive environment, typically -55°C to +125°C
- ESD Protection: Clamped diodes for input pins, suitable for industrial environments
- Operating Current (I/O segment): 0.42 mA per GPIO in typical operation
- External Oscillator: Crystal frequency 8-40 MHz, recovery time 0.5 ms
- Package: 416-ball MAPBGA, with integrated stray capacitances 2.3-3.0 pF
- VCO Frequency: 600-1250 MHz with jitter specified at 200 ps (6-sigma)
- PLL Lock Time: approximately 100 µs, jitter peak-to-peak 250 ps
- Power Management: Supports multiple voltage monitoring and power sequencing features
Buy the Buy NXP Semiconductors MPC5775E Part Number SPC5775BDK3MME2 Online
Purchase the NXP Semiconductors MPC5775E microcontroller online today. Designed for automotive and industrial applications, it features advanced power management, robust I/O options including LVDS and CMOS interfaces, and supports external crystal oscillators up to 40 MHz. The device offers excellent temperature stability and reliable data retention, making it ideal for complex control systems demanding high precision, durability, and efficient power sequencing. Order now for quick delivery and ensure your project benefits from industry-leading technology.
Get NXP Semiconductors MPC5775E today—built for automotive reliability, high-speed processing, and extensive I/O flexibility.
Frequently Asked Questions
Where can I buy NXP SPC5775BDK3MME2?
You can click on the BUY or RFQ button to purchase SPC5775BDK3MME2 from an authorized NXP distributor.
How do I troubleshoot issues or seek technical support for part SPC5775BDK3MME2?
You can download the SPC5775BDK3MME2 datasheet or visit the NXP website for support.
Who is the manufacturer of SPC5775BDK3MME2?
NXP
