OMEGA D8200 Current Input Module
This USB data acquisition interface module features a 7-channel differential current input capable of measuring ±20mA. It connects via USB and supports Modbus RTU protocol, allowing up to 25 conversions per second. The module offers continuous self-calibration, requiring no adjustments, and operates with a 10 to 30V DC unregulated power supply. It includes removable screw terminal connectors for easy connection. Suitable for process monitoring, control applications, product testing, and data logging to any host computer. The kit comes with the module, operator's manual, utility software on CD, and a 0.9-meter USB interface cable.
OMEGA D8200 Current Input Module Specifications:
- Number of Channels: 7 differential current inputs
- Range: +20 mA
- Resolution: 16-bit ADC, 25/20 conversions per second
- Accuracy: +0.05% of FS max
- Span Tempco: +50 ppm/°C max
- Input Impedance: <100 Ω (70 typical)
- Electrical Protection: Input to 250 Vac
- Power Requirements: Serial power = 1.4 W
- Supply Voltage: 10 to 30 Vdc, unregulated
- Operating Temperature Range: -25 to 70°C
- Storage Temperature Range: -25 to 85°C
- Relative Humidity: 0 to 95% RH non-condensing
- Dimensions: 18.1 x 7.14 x 3.6 cm (7.14 x 2.8 x 1.5 inches)
- Connectors: Screw terminal barrier plug
- Communication Protocol: Modbus RTU via USB
- Environmental: Rugged ABS case, UL-94V-0 rated
Buy the OMEGA Series D8200 Current Input: 7-channel Differential Module
Order the OMEGA D8200 current input module online now for precise ±20mA measurement capability, 16-bit resolution, easy USB connectivity, and reliable self-calibration. Perfect for process control, testing, and data logging, this rugged module includes screw terminal connectors and supports Modbus RTU protocol. Compact and simple to install, it provides high accuracy in industrial environments. Take advantage of fast order processing, secure checkout, and immediate shipment to enhance your data acquisition setup efficiently. Buy online today to get unmatched performance.
Get OMEGA D8200 today—built for precision and long-lasting durability in current measurement applications.
