OMEGA DPI32 Digital Panel Meter
The DPi Series is a family of high-accuracy, microprocessor-based digital panel meters and controllers designed for temperature, strain, and process measurements. Featuring programmable color displays, embedded internet connectivity, and selectable serial communication options, these instruments handle thermocouples, RTDs, voltage, current, and strain inputs with easy configuration and calibration. With extended warranties, multiple power options, and environmental ratings, the DPi Series provides versatile, reliable measurement solutions suitable for industrial automation, process control, and engineering applications.
OMEGA DPI32 Digital Panel Meter Specifications:
- Accuracy: +0.5°C temperature; 0.03% reading
- Temperature Stability: RTD 0.04°C/°C, Thermocouple 0.05°C/°C at 25°C
- Input Types: Thermocouple, RTD, analog voltage, current
- Thermocouple Types: J, K, T, E, R, S, B, C, N, L (J DIN)
- RTD Input: 100/500/1000 2 wire, 0.00385 or 0.00392 curve
- Voltage Input: 0 to 100 mV, 0 to 1V, 0 to 10 V; Impedance: 10 MΩ for 100 mV, 1 MΩ for 1V/10V
- Current Input: 0 to 20 mA with 5 Ω load
- Resolution: 1°/0.1°, 10 μV process
- Digital Filter: Programmable
- Display: 4-digit 9-segment LED with color-changing capability
- Power Supply: 90-240 Vac or 24 Vac/DC options
- Dimensions: 48 H x 96 W x 127 mm D for iSeries model
- Panel Cutout: 45 H x 92 W mm (1.772 x 3.622")
- Environmental Rating: NEMA 4X/IP65 front bezel (certain models)
- Communication: Ethernet (TCP/IP), RS232/RS485/RS422, ASCII/MODBUS
- Approvals: UL, C-UL, CE, FM
Buy the Omega Series DPi Temperature Processor: DPI32
Order the Omega DPi32 digital panel meter online today to enhance your temperature, strain, and process measurement systems. Combining high accuracy, programmable RGB color displays, and versatile communication options, this unit is perfect for process control applications. Its rugged NEMA 4X/IP65 front bezel ensures durability in harsh environments. With easy setup, built-in calibration, and complete documentation, purchasing online guarantees quick delivery, reliable performance, and integration into your automation system, all backed by an extended warranty and excellent technical support.
Get Omega DPi32 today—built for precise temperature and strain measurement in industrial environments.
Frequently Asked Questions
Where can I buy OMEGA DPI32?
You can click on the BUY or RFQ button to purchase DPI32 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DPI32?
You can download the DPI32 datasheet or visit the OMEGA website for support.
Who is the manufacturer of DPI32?
OMEGA
