OMEGA FLR6102D Flow Sensor
This flow meter is designed for process control and information systems, featuring a flow range of 0.2 to 2.0 GPM and suitable for oil media. Constructed with an aluminum body, it provides a 2% full scale accuracy. The device can be mounted in any position and includes a digital flow rate and total flow indicator for precise measurement and monitoring. It operates within a temperature range of -29 to 116°C (-20 to 240°F) and can withstand pressures up to 3500 psig for liquids. Equipped with analog outputs (4-20 mA, 0-5 V, 0-10 V) and built with durable materials like anodized aluminum and brass, ensuring reliable and accurate flow measurement in industrial applications.
OMEGA FLR6102D Flow Sensor Specifications:
- Flow Range: 0.2 to 2.0 GPM
- Medium: Oil
- Materials: Aluminum body, C360 brass components
- Maximum Pressure: 3500 psig (liquids), 1000 psig (gases)
- Temperature Range: -29 to 116°C (-20 to 240°F)
- Power Requirements: 0 to 5 Vdc @ 10-30 Vdc, 0 to 10 Vdc @ 12-30 Vdc, 4-20 mA loop-powered
- Power Consumption: 0.75 W maximum
- Output: Digital flow rate and totalizer, 8-digit display
- Cable Length: Standard 15 ft, extendable up to 300 m
- Enclosure: Anodized aluminum with polycarbonate lens, NEMA 12/13 rated
- Pressure Seals: FKM
- Response Time: 1.0 second
- Temperature Drift: 0.05% of span per °C
Buy the Omega FLR6102D – Reliable Flow Sensor for Industrial Applications
Order the Omega flow sensor for oil with a 0.2–2.0 GPM range and 2% accuracy. Designed for process control, it features durable aluminum construction, digital display, flexible mounting options, and reliable analog outputs. Perfect for industrial environments, this device ensures precise flow monitoring and easy installation. With high-pressure ratings and all necessary seals, it supports demanding applications. Buy online now and enhance your fluid measurement systems with this rugged, accurate flow sensor built to withstand tough conditions.
Get Omega FLR6102D today—built for precision and long-lasting durability in fluid measurement.
Frequently Asked Questions
Where can I buy OMEGA FLR6102D?
You can click on the BUY or RFQ button to purchase FLR6102D from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part FLR6102D?
You can download the FLR6102D datasheet or visit the OMEGA website for support.
Who is the manufacturer of FLR6102D?
OMEGA
