OMEGA SSRL240DC100 Solid State Relay
The SSRL240DC100 is a high-reliability solid state relay designed for industrial applications, featuring DC control input and AC load output up to 100A. It’s suitable for use with temperature controllers and capable of switching large resistance heaters with no moving parts, providing millions of cycles. Its twin SCR design ensures higher overload capacity than triacs. Proper mounting on finned heat sinks and protection with fast blow fuses are essential for safe operation. Ideal for automation systems requiring dependable, long-lasting switching performance.
OMEGA SSRL240DC100 Solid State Relay Specifications:
- Control Signal Type: DC
- Control Signal Voltage: 3 to 32 Vde
- Load Current: 100A
- Max AC Line Voltage: 240 Vac
- Switching Voltage Drop: 1.6V
- Maximum Surge Current: 150A (60 cycles), 30A (1 sec)
- Isolation: 4000 Vrms, input to output
- Operating Temperature: -20 to 80°C
- Thermal Resistance: 1.2°C/W (FHS-2 heat sink)
- Mounting: Finned heat sink required, with tapped holes
- Fuses Recommended: Fast blow type for load protection
- Compatibility: Temperature controllers for resistive loads
- Cycle Life: Millions of switching cycles
- Leakage Current: Small leakage across open relay
Buy the Omega SSRL240DC100 – Reliable DC Control for Industrial Applications
Order the Omega SSRL240DC100 online today to ensure reliable DC control and high current switching for your industrial automation and resistance heating needs. Designed for high overload capacity and long cycle life, this solid state relay offers safe, noise-free operation with small leakage current. Compatible with temperature controllers, it improves efficiency and safety in manufacturing systems. Purchase now and benefit from fast shipping, trusted quality, and excellent performance tailored for demanding industrial environments.
Get Omega SSRL240DC100 today—built for precision, high current switching, and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy OMEGA SSRL240DC100?
You can click on the BUY or RFQ button to purchase SSRL240DC100 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part SSRL240DC100?
You can download the SSRL240DC100 datasheet or visit the OMEGA website for support.
Who is the manufacturer of SSRL240DC100?
OMEGA
