OMEGA LBC012 Load Cell
The LC1102 series stainless steel canister load cells offer high accuracy and reliability for tension and compression measurements up to 100,000 pounds. Calibrated with 5-point NIST-traceable calibration, these load cells feature a 3 mV/V output, IP67 protection, and an operating temperature range of -24 to 79°C. They include dual-bridge models and optional extended temperature ranges, making them ideal for industrial weighing, force measurement, and industrial automation. Their compact design and optional integral connectors facilitate easy installation and integration into various system setups.
OMEGA LBC012 Load Cell Specifications:
- Output: 3 mV/V +0.25% FSO
- Excitation: 10 Vdc (15V maximum)
- Accuracy Class: +0.05% FSO
- Linearity: +0.05% FSO / +0.02% FSO
- Zero Balance: +1.0% FSO
- Operating Temp Range: -24 to 79°C (-30 to 175°F)
- Compensated Temp Range: 16 to 71°C (60 to 160°F)
- Thermal Zero Effect: +0.003% FSO/°C
- Thermal Span Effect: +0.014% FSO/°C
- Protection Class: IP67
- Safe Overload: 150% of capacity
- Ultimate Overload: 300% of capacity
- Bridge Resistance: 350 Q
- Full Scale Deflection: 0.08 to 0.13 mm (0.003 to 0.005")
- Electrical Cable: 4.6 m (15') shielded 4-conductor cable
- Materials: Stainless steel construction for durability and corrosion resistance
Buy the Omega Series Load Cell: LC1102-100K
Discover the precision and durability of the Omega Series Load Cell LC1102-100K, designed for high-capacity tension and compression measurements. Featuring stainless steel construction, a 3 mV/V output, and IP67 protection, this load cell provides reliable performance in demanding industrial environments. With optional dual-bridge configurations and extended temperature ranges, it is suitable for weighing, force measurement, and automation applications. Easy to install with optional connectors, it ensures consistent, accurate readings, supporting your project's high standards for safety and precision.
Order your Omega Series Load Cell LC1102-100K today and give your measurement systems the dependable, high-accuracy performance they deserve.
Frequently Asked Questions
Where can I buy OMEGA LBC012?
You can click on the BUY or RFQ button to purchase LBC012 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part LBC012?
You can download the LBC012 datasheet or visit the OMEGA website for support.
Who is the manufacturer of LBC012?
OMEGA
