OMEGA LCR25 Load Cell
The Omega LCR-25 is a high-precision, rugged S-Beam load cell ideal for industrial and weighing applications. Capable of measuring up to 25 lb (11 kgf), it features a 3 mV/V output, ±0.25% accuracy, ±0.03% linearity, and operates within -18°C to 71°C (0°F to 150°F). Constructed from lightweight aluminum, it offers high interchangeability, overload capacity of 150%, and ultimate overload of 300%. The device is protected at IP55 and compatible with digital meters for precise force measurement in industrial environments.
OMEGA LCR25 Load Cell Specifications:
- Capacity: 25 lb (11.34 kgf)
- Output: 3 mV/V ±0.25%
- Excitation Voltage: Max 15 VDC
- Linearity: ±0.03%
- Hysteresis: ±0.02%
- Repeatability: ±0.10%
- Temperature Range: -18°C to 71°C (0°F to 150°F)
- Overload Capacity: 150% of capacity, 300% ultimate
- Protection Level: IP55
- Material: Lightweight aluminum
- Operating Temperature: -18°C to 71°C
- Electrical Connection: 6 m (20') cable
Buy the Buy Omega Load Cell Part Number LCR25 Online
Purchase the Omega LCR-25 high-accuracy load cell online for reliable force measurements in industrial applications. Precision-engineered with a rugged aluminum design, it offers an output of 3 mV/V, high linearity, and excellent overload capacity. Ideal for integrators and weighing systems, it features IP55 protection, compatibility with digital meters, and a temperature range of -18°C to 71°C. Secure your measurement needs today with fast and easy online ordering for this durable, precision load sensing component.
Get Omega LCR-25 today—built for precision, durability, and industrial-force measurement accuracy.
