OMEGA SP0021 Infrared Temperature Sensor
The Omega Smart IR Temperature Probe is a compact, stainless steel non-contact infrared sensor suitable for heavy industrial environments, measuring surface temperatures from -70 to 380°C. It features adjustable emittance, configurable optical field of view options of 6:1 or 10:1, and advanced IoT capabilities including data logging for up to 1499 readings. This IP67-rated probe is ideal for measuring various materials like plastics, rubber, food, painted metals, and dirty surfaces, with easy software configuration and built-in ambient temperature sensors for safety and accuracy in demanding industrial settings.
OMEGA SP0021 Infrared Temperature Sensor Specifications:
- Temperature Range: -70 to 380°C
- Accuracy @ 0 to 50°C: 1°C or 1.8°F, or 1% of reading
- Accuracy over entire range: 4°C or 3% of reading
- Repeatability: 1°C or 1% of reading
- Emissivity: 0.01 to 1.00, adjustable via software
- Response Time: 1 second
- Spectral Response: 5.5 to 14 microns
- Supply Power: 3.3 Vdc, 0.05 W max
- Field of View: 6:1 or 10:1 depending on model
- Construction: Stainless Steel
- Sensor Dimensions: 12 mm OD x 67 mm L
- Thread Mounting: 12 mm OD x 33.5 mm L
- Weight: 35 g
- Environmental Rating: NEMA 6, IP67
- Operating Temperature: -40 to 85°C
- Vibration Resistance: 10 Gs from 10 Hz to 500 Hz
- Certifications: CE, EMC, LVD
Buy the Buy Omega Infrared Temperature Probe Part Number SP0021 Online
Order the Omega SP0021 infrared temperature sensor online today to harness advanced non-contact temperature measurement technology. Its compact stainless steel design ensures durability in heavy industrial environments, measuring surfaces from -70 to 380°C with high accuracy. The adjustable emissivity, configurable optical field of view, and integrated IoT data logging make this sensor a perfect fit for diverse applications like plastics, rubber, and painted metals. Easy software configuration, IP67 rating, and robust construction guarantee reliable performance and seamless integration into your control system.
Buy Omega SP0021 infrared temperature sensor now and experience unmatched reliability and precise non-contact temperature measurement for industrial applications.
Frequently Asked Questions
Where can I buy OMEGA SP0021?
You can click on the BUY or RFQ button to purchase SP0021 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part SP0021?
You can download the SP0021 datasheet or visit the OMEGA website for support.
Who is the manufacturer of SP0021?
OMEGA
