OMEGA PSW111015CPI Digital Pressure Switch
The PSW-1110 is a compact digital pressure switch designed for non-corrosive gases, featuring a bright 4-digit display, two programmable PNP outputs, and multiple pressure units including psi, bar, KPa, and more. Its ultra-compact cube shape allows easy installation with horizontal and vertical port options. Key specifications include accuracy of +1% FS, response time of 135 ms, burst pressure of 300 psi, and operating temperature range from -10°C to 60°C. It supports multiple operation modes such as hysteresis and window modes, with customizable pressure ranges and port thread types for diverse industrial applications.
OMEGA PSW111015CPI Digital Pressure Switch Specifications:
- Accuracy: +1% FS
- Repeatability: +1% FS
- Response Time: 135 ms
- Burst Pressure: 300 psi
- Compatible Media: Non-Corrosive Gases
- Supply Voltage: 10-30 Vdc
- Electrical Connection: 20" Cable with Flying Leads
- Current Consumption: <80 mA
- Output: PNP
- Media Temperature Range: 0 to 100°C (32 to 212°F)
- Temperature Accuracy: +2°C (+4°F)
- Operating Temperature: -10 to 60°C (14 to 140°F)
- Storage Temperature: -20 to 70°C (-4 to 158°F)
- Operating & Storage Humidity: 35 to 85% RH
- Process Connection Material: Zinc Alloy
- Enclosure Materials: ABS
- Weight: 80g
- Shock Resistance: 100g (980 m/s²)
- Acceleration: 10g (98 m/s²)
- Vibration: 10 to 500 Hz frequency, 0.06 in (1.5 mm) amplitude
Buy the Buy Oz OMEGA Pressure Switch Part Number PSW111015CPI Online
Purchase the Oz OMEGA PSW-1110 digital pressure switch online to ensure precise pressure monitoring in your non-corrosive gas systems. Its compact, 1-inch cube housing fits easily into tight spaces and offers dual port options for flexible installation. The bright multi-colored display provides clear readings, while the fully programmable PNP outputs and pressure units make it versatile for various applications. With accuracy within +1% FS, response in 135 ms, and configurable hysteresis and window modes, this switch enhances operational efficiency and reliability in industrial environments.
Buy Oz OMEGA PSW-1110 pressure switch now and experience unmatched reliability, compact design, and versatile operation modes ideal for your application.
Frequently Asked Questions
Where can I buy OMEGA PSW111015CPI?
You can click on the BUY or RFQ button to purchase PSW111015CPI from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PSW111015CPI?
You can download the PSW111015CPI datasheet or visit the OMEGA website for support.
Who is the manufacturer of PSW111015CPI?
OMEGA
