OMEGA PX3005160WDWBI Differential Pressure Transmitter
The Omega PX3005-DIFF is a compact, rangeable, differential pressure transmitter with a digital display, ideal for process automation, hydraulic systems, and tank level monitoring. Constructed with a rugged 316 stainless-steel enclosure, IP67 rated for washdown environments, it features a MEMs piezoresistive sensor and microprocessing for high accuracy and reliability. The transmitter offers adjustable zero and span from -100 to 100% of its range, with various measurement units, a backlit LCD, and configurable 4-20 mA output signal. Suitable for wet/wet conditions, it ensures durable, precise pressure measurement in demanding industrial settings.
OMEGA PX3005160WDWBI Differential Pressure Transmitter Specifications:
- Accuracy: +0.075% span, long-term stability: +0.2% URL/60 months
- Supply Voltage: 10.5 to 55VDC, Power Consumption: 500mW
- Output Signal: 4 to 20mA, linear or square root, two-wire
- Measurement Range: -70 to 150 psi, -70 to 160 inH2O, 1 to 1500 psi, and other ranges
- Environmental Rating: IP67, Enclosure Material: 316 stainless steel
- Operating Temperature: -20°C to 70°C, Storage Temperature: -40°C to 85°C
- Process Connection: ½" NPT F/316 SS, Electrical Connection: 4-pin M12
- Sensor Fill Fluid: Silicone Oil, Sensor Seal: FKM O-ring
- Vibration Resistance: 20g (IEC 61298-3), Response Time: 200 ms
- Damping Time: 0-100 s, Transmission Distance: < 1000 m
Buy the Omega PX3005-DIFF – Reliable Differential Pressure Transmitter for Industrial Applications
Discover the Omega PX3005-DIFF, a rugged differential pressure transmitter designed for industrial environments requiring precise pressure monitoring. Featuring a stainless-steel IP67 enclosure, a backlit LCD, and configurable ranges, it offers flexible measurement options suitable for process automation, hydraulic systems, and tank level applications. Its MEMs sensor provides high accuracy and stability over time, while the adjustable zero/span and user-selectable units make it adaptable. Choose Omega PX3005-DIFF for reliable, long-lasting pressure sensing in harsh industrial settings.
Get Omega PX3005-DIFF today—built for precise and durable industrial pressure measurement in demanding environments.
Frequently Asked Questions
Where can I buy OMEGA PX3005160WDWBI?
You can click on the BUY or RFQ button to purchase PX3005160WDWBI from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PX3005160WDWBI?
You can download the PX3005160WDWBI datasheet or visit the OMEGA website for support.
Who is the manufacturer of PX3005160WDWBI?
OMEGA
