OMEGA PX3005400DWBI Pressure Transmitter
The Omega PX3005-DIFF Pressure Transmitter with Display is a compact, rangeable sensor designed for accurate pressure measurement in hydraulic, process automation, and tank applications. Featuring a robust 316 stainless steel enclosure rated IP67, it withstands washdown environments and high line pressures. Equipped with a 5-digit backlit LCD, it displays process variables, configurable in 19 units. The device offers adjustable zero/span from -100 to 100% FS, with output options including 4-20 mA and linear or square root conversion. Ideal for diverse industrial environments needing precise, durable pressure measurement.
OMEGA PX3005400DWBI Pressure Transmitter Specifications:
- Power Supply: 10.5 to 55VDC
- Output Signal: 4 to 20mA, two-wire, linear or square root output selectable
- Accuracy: ±0.075% span (NLHR, 20°C +5°C)
- Long Term Stability: ±0.2% URL/60 months
- Operating Temperature: -20 to 70°C (-4 to 160°F)
- Environmental Rating: IP67, stainless steel enclosure
- Media Temperature: -40 to 120°C (-40 to 250°F)
- Process Connection: ½ inch NPT female, 316 SS
- Sensor Fill Fluid: Silicone Oil
- Housing Material: 316 stainless steel
- Weight: Approx. 3 kg
- Isolation Diaphragm: 316L stainless steel
- Vibration Resistance: Up to 20g (IEC61298-3 tested)
- Display: 5-digit backlit LCD
- Range: -70 to 150 psi, -160 to 160 inH2O, 1 to 1500 psi, etc.
- Certifications: IP67 rated
Buy the Omega Series PX3005 Differential Pressure Transmitter: PX3005-400DWBI
Order the Omega PX3005-400DWBI Pressure Transmitter online today and enjoy reliable pressure measurement with IP67 protection in demanding environments. This compact and durable device features a backlit LCD display, adjustable zero/span, and versatile output options including 4-20 mA for seamless integration into your automation system. With its high accuracy, long-term stability, and robust stainless steel enclosure, it is ideal for hydraulic, process, and tank applications. Purchase now for precise, durable, and easy-to-configure pressure monitoring solutions.
Get Omega PX3005-400DWBI today—built for precision and long-lasting durability in industrial pressure monitoring.
Frequently Asked Questions
Where can I buy OMEGA PX3005400DWBI?
You can click on the BUY or RFQ button to purchase PX3005400DWBI from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PX3005400DWBI?
You can download the PX3005400DWBI datasheet or visit the OMEGA website for support.
Who is the manufacturer of PX3005400DWBI?
OMEGA
