OMEGA PX633M20 Submersible Level Transmitter
The PX633 series high-accuracy submersible level transmitter is designed for demanding liquid level measurement applications. Features include advanced microprocessor technology, dual sealing, and full potting for durability. The rugged stainless steel body with an inverted cone seal ensures long-term reliability in turbulent environments. It offers a range of pressure options from 3 psi to 300 psi with accuracies from 0.1% to 0.5% of full scale. Suitable for submerged applications, it includes comprehensive temperature compensation, transient voltage protection, CE certification, and is fully calibrated and tested for precision and stability in harsh industrial conditions.
OMEGA PX633M20 Submersible Level Transmitter Specifications:
- Accuracy: 0.01% FS NLHR (PX633A1), 0.25% FS NLHR (PX633A2), 0.50% FS NLHR (PX633A5)
- Long Term Stability: +0.2% FS per year
- Operating Temperature: -10 to 70°C
- Storage Temperature: -30 to 80°C
- Supply Voltage: 10.5 to 55VDC
- Output Signal: 4 to 20mA DC
- Maximum Current: 20.8mA
- Protection Class: IP68
- Electrical Connection: PUR cable, 7.5mm diameter
- Sensor Material: 316 SS
- Fill Fluid: Silicon oil
- Diaphragm Material: 316 SS
- Vibration Resistance: 20g (IEC61298-3/GB/T 18271.3)
- Operation in harsh environments with CE certification, transient voltage protection, and calibration.
- Range: 3 psi to 300 psi variants, with respective accuracies and calibration details.
- Transmission Distance: Up to 1000m, Power Consumption: 500mW at 24VDC.
Buy the Omega Series Submersible Pressure Transmitter: PX633M20
Purchase the Omega Series PX633M20 submersible level transmitter online now for precise, reliable liquid level measurement in challenging conditions. This rugged device features advanced microprocessor technology, full potting, dual seal design, and high static accuracy. Suitable for a wide range of pressures from 3 to 300 psi, it offers excellent long-term stability, temperature compensation, and CE certification. With easy installation and calibration, it’s the ideal choice for industrial liquid monitoring applications demanding durability, accuracy, and dependable performance over time.
Order your Omega Series PX633M20 high-accuracy submersible pressure transmitter today and ensure reliable liquid level measurement in demanding environments.
Frequently Asked Questions
Where can I buy OMEGA PX633M20?
You can click on the BUY or RFQ button to purchase PX633M20 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PX633M20?
You can download the PX633M20 datasheet or visit the OMEGA website for support.
Who is the manufacturer of PX633M20?
OMEGA
