OMEGA REC014F Load Cell
The LC201 series subminiature load cell is designed for industrial automation and robotics, offering high accuracy and durability in harsh environments. With a diameter of 0.75 inches and all stainless steel construction, it fits into small spaces while providing reliable tension and compression measurements. It features a 10 Vdc excitation, 2 mV/V output, IP54 protection, and a safe overload capacity of 150%. Suitable for various ranges from 25 to 300 pounds, it comes with a 5-point calibration and dual mounting studs for easy installation.
OMEGA REC014F Load Cell Specifications:
- Diameter: 0.75 inches (19 mm)
- Material: Stainless steel
- Range: 25 to 300 pounds (various models available)
- Excitation: 10 Vdc, 15 Vdc max
- Output: 2 mV/V nominal
- Accuracy: ±1.0% FSO including linearity, hysteresis, repeatability
- Zero Balance: +2% FSO
- Operating Temp Range: -54 to 121°C (-65 to 250°F)
- Protection Class: IP54
- Thermal Zero Effect: 0.018% FSO/°C
- Thermal Span Effect: 0.018% FSO/°C
- Overload Capacity: 150% safe, 300% ultimate
- Input Resistance: ≥360 Q
- Output Resistance: 350 Q ±10 Q
- Electrical Cable Length: 1.5 m (5 feet)
- Calibration: 5-Point NIST traceable
- Mounting: Dual studs for easy installation
Buy the Newport Series LC201 Load Cell: 0.75 inch Diameter Tension and Compression Sensor
Experience reliable tension and compression measurement with this stainless steel load cell, perfect for robotics and industrial automation. Its compact size of 0.75 inches ensures easy integration into small systems. With a calibrated accuracy of ±1.0% FSO, it provides long-term stability across a wide temperature range from -54°C to 121°C. Designed with dual mounting studs, IP54 protection, and a 5-point NIST traceable calibration certificate, it guarantees precision and durability in demanding environments. Enhance your automation solutions today.
Buy Newport LC201 load cell now and ensure high accuracy and durability in robotic and industrial automation applications.
