OMEGA HH376 RTD Data Logger
The HH376 is a high-accuracy RTD thermometer with a built-in data logger capable of storing 16,000 readings at user-defined intervals. It features a 5-digit backlit LCD, MAX/MIN/HOLD functions, and automatic power-off for prolonged use. Equipped with a precision 4-wire Pt100 RTD probe with an automatic lock connector, it delivers ±0.05% reading accuracy within -100 to 400°C. The device supports real-time data monitoring via USB or RS232, with software included. Its rugged design, dual display, and adjustable offset make it ideal for precise temperature measurements in industrial and laboratory environments.
OMEGA HH376 RTD Data Logger Specifications:
- Numerical Display: 5-digit LCD
- Measurement Range: -100 to 400°C (-148 to 752°F)
- Resolution: 0.01°C (0.02°F)
- Sensor Type: Pt100 4-wire
- Temperature Accuracy: ±0.05% reading + 0.1°C
- Environmental Operating Conditions: 0-50°C, RH 0-80%
- Storage Temperature: -10 to 60°C, RH 0-80%
- Sample Rate: 2 times/sec
- Dimensions: 185 x 65 x 36 mm
- Weight: approximately 360 g
- Power: 9V battery (included), approx. 100 hours life
- Probe Sheath Diameter: 5.0 mm
- Probe Sheath Length: 230 mm
- Cable Length: 1500 mm
- Power Adapter: 9 VDC (7-10V), 20 mA
- Display: Large backlit dual LCD
- Additional Features: MAX/MIN/HOLD, auto power off, user offset
- Connectivity: USB with Windows software, RS232 (optional)
Buy the Buy Omega HH376 Precision RTD Part Number HH376 Online
Order the Omega HH376 high-accuracy RTD thermometer with integrated data logger online today. This versatile device stores up to 16,000 readings, features a precision 4-wire Pt100 probe, large dual LCD display, and USB connectivity for real-time data analysis. Perfect for industrial, laboratory, and quality control environments, it ensures precise temperature measurements with a 0.01°C resolution. The kit includes software, probe, carrying case, and battery, providing all you need for accurate temperature monitoring and recording in a compact, portable design.
Buy Omega HH376 precision RTD thermometer with data logger now and experience reliable temperature monitoring for industrial and laboratory applications.
Frequently Asked Questions
Where can I buy OMEGA HH376?
You can click on the BUY or RFQ button to purchase HH376 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part HH376?
You can download the HH376 datasheet or visit the OMEGA website for support.
Who is the manufacturer of HH376?
OMEGA
