OMEGA XBTKT25 Thermocouple Terminal Block
Thermocouple terminal blocks are essential components for making reliable connections in temperature measurement systems. Offered in Type J, K, T, E, and R, these blocks feature thermocouple-grade calibration alloys for precise readings. They are designed with screw-type connections for secure attachment and are compatible with DIN connectors. The blocks support large wire sizes up to 12 AWG, feature a terminal width of 10.4 mm, and have an insulated temperature range of -40 to 125°C. Their robust construction ensures maintenance-free, durable connections suitable for industrial temperature sensing applications.
OMEGA XBTKT25 Thermocouple Terminal Block Specifications:
- Terminal Width: 10.4 mm (0.41")
- Maximum Wire Size: 12 AWG/2.5 mm²
- Connection Data in V/AWG: 400/24-12 Type K
- UL-cUL Ratings in V/A/AWG: 300/10/28-12
- Length: 46.0 mm (1.81")
- Cover Width: 1.0 mm (0.04")
- Height for 35 x 7.5/35 x 15 mm: 40.0 mm (1.57") / 47.5 mm (1.87")
- Stripping Length: 7 mm (0.28")
- Thread: M3
- Torque: 0.6 to 0.8 inch-lb (5.3 to 7.1 Nm)
- Insulated Temperature Range: -40 to 125°C (-40 to 257°F)
Buy the Thermoelectric Series XBTK Thermocouple Terminal Blocks: XBTKT25
Enhance your temperature measurement setup with our Thermocouple Terminal Block series, available in Type J, K, T, E, and R. Designed for industrial environments, these blocks feature secure screw connections, support up to 12 AWG wires, and operate reliably from -40°C to 125°C. Made with thermocouple-grade alloys, they ensure precise temperature readings. Easy to install and maintain, these terminal blocks are essential for accurate and durable temperature sensing in control systems. Upgrade your instrumentation today with our premium terminal blocks.
Get Thermoelectric Series XBTK thermocouple terminal blocks today—built for secure connections and industrial-grade temperature sensing accuracy.
Frequently Asked Questions
Where can I buy OMEGA XBTKT25?
You can click on the BUY or RFQ button to purchase XBTKT25 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part XBTKT25?
You can download the XBTKT25 datasheet or visit the OMEGA website for support.
Who is the manufacturer of XBTKT25?
OMEGA
