ONSEMI FOD8173T High-Speed Optocoupler
The FOD8173T is a high-speed, reliable optocoupler packaged in a stretched body 6-pin SOP designed for industrial applications. It features a GaAlAs LED and CMOS detector IC, ensuring excellent electrical isolation, high noise immunity with a minimum of 20kV/µs CMTI, and a data rate of 20 Mbit/sec with a 55 ns propagation delay. Suitable for interface circuits like microprocessors, CAN, RS485, and voltage level translation, it guarantees safety and insulation ratings per DIN EN/IEC standards with a wide industrial temperature range of -40°C to 100°C.
ONSEMI FOD8173T High-Speed Optocoupler Specifications:
- Package: Stretched body SOP 6-Pin
- Operating Temperature: -40°C to +100°C
- Storage Temperature: 40°C to +125°C
- Input Voltage: 3.0 V to 5.5 V
- Input Current: 20 mA (max)
- Output Voltage: 0.5 V to VDD + 0.5 V
- Output Current: 10 mA (max)
- Propagation Delay: 55 ns (max)
- Data Rate: 20 Mbit/sec
- CMTI: ≥20kV/μs
- Isolation Voltage: 5,000 VACrms
- Insulation Resistance: >10^9 Ω
- Creepage and Clearance: 8.0 mm
- Insulation Capacitance: 1.0 pF
- Maximum Insulation Voltage: 891 Vpeak (VIO), 1,140 Vpeak (VIRM)
- Lead Solder Temperature: 260°C for 10 sec
Buy the ON Semiconductor FOD8173T – Reliable High-Speed Optocoupler for Industrial Applications
Purchase the ON Semiconductor FOD8173T online today and enjoy seamless integration into your industrial automation projects. This high-speed optocoupler offers excellent electrical isolation, a data rate of 20 Mbit/sec, and peak insulation voltage of 1,140 Vpeak. Ideal for microprocessor interface, CAN, RS485, and voltage level translation, it guarantees reliable performance over a wide temperature range from -40°C to 100°C. Secure your supply chain by buying online and ensuring your applications stay safe, efficient, and compliant with industry standards.
Buy ON Semiconductor FOD8173T now and experience unmatched reliability and high-speed communication for industrial automation and safety isolation needs.
Frequently Asked Questions
Where can I buy ONSEMI FOD8173T?
You can click on the BUY or RFQ button to purchase FOD8173T from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part FOD8173T?
You can download the FOD8173T datasheet or visit the ONSEMI website for support.
Who is the manufacturer of FOD8173T?
ONSEMI
