ONSEMI SMF12CT1G Voltage Suppressor Array
The SMF12CT1G is a five-line transient voltage suppressor array designed to protect sensitive electronic equipment from voltage spikes and ESD events. It supports up to 12V working voltage, offers peak power dissipation of 100W, and is IEC 61000-4-2 compliant, exceeding 8 kV ESD ratings. Ideal for automotive, networking, telecom, and computer applications, the monolithic design safeguards five independent lines within a compact SC-88 package, ensuring reliable over-voltage protection for critical devices.
ONSEMI SMF12CT1G Voltage Suppressor Array Specifications:
- Peak Power Dissipation: 100 W (8 x 20 us Waveform)
- Maximum Reverse Working Voltage: 12 V
- Breakdown Voltage: 13.3 to 15 V at 1 mA
- Reverse Leakage Current: 0.01 to 0.04 A at Vwm
- Clamping Voltage: 24 V at 3A, 23 V at 6A
- Maximum Peak Pulse Current: 6.0 A
- Capacitance: 40 to 60 pF (Line to GND)
- IEC 61000-4-2 ESD Rating: 15,000 V (Air), 15,000 V (Contact)
- Operating Temperature Range: -40°C to 125°C
- Flammability Rating: UL94 V-0
- Package: SC-88
- Number of Lines Protected: 5
Buy the ON Semiconductor SMF12CT1G – Reliable Voltage Suppressor for Industrial Applications
Secure your electronic equipment against voltage surges and ESD with the SMF12CT1G five-line transient voltage suppressor array. This compact device supports up to 12V reverse working voltage and dissipates peak power of 100W, making it ideal for automotive, networking, and industrial applications. Fully IEC 61000-4-2 compliant, it provides superior protection with an ESD rating exceeding 8 kV and a UL94 V-0 flammability rating. Protect your critical systems with this reliable, high-performance device today.
Buy ON Semiconductor SMF12CT1G now and experience unmatched reliability and performance in transient voltage suppression for industrial and electronic devices.
Frequently Asked Questions
Where can I buy ONSEMI SMF12CT1G?
You can click on the BUY or RFQ button to purchase SMF12CT1G from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part SMF12CT1G?
You can download the SMF12CT1G datasheet or visit the ONSEMI website for support.
Who is the manufacturer of SMF12CT1G?
ONSEMI
