ONSEMI FSA3357K8X Analog Switch
The FSA3357 is a high-performance, low-voltage SP3T analog switch designed for both analog and digital applications. Fabricated with advanced CMOS technology, it features high-speed enable/disable times, low On Resistance (< 90Ω at 3.3V), and a broad operating voltage range from 1.65V to 5.5V. Its break-before-make circuitry prevents signal disruption during switch transitions. The device is available in space-efficient 8-lead MicroPak and US8 packages, with overvoltage control input tolerance up to 7.0V, making it suitable for space-constrained, high-speed switching applications like cell phones, PDAs, and video equipment.
ONSEMI FSA3357K8X Analog Switch Specifications:
- Device Type: SP3T Analog Switch
- Technology: CMOS
- On Resistance: < 90Ω @ 3.3V VoG
- Voltage Range: 1.65V to 5.5V
- Control Input Tolerance: Up to 7.0V
- Bandwidth: 250 MHz - 3dB
- Package Options: MicroPak 8-Lead, US8
- Switch Resistance Match: 0.18Ω between channels at specified conditions
- Break before make circuitry ensures signal integrity during switching
- Input Capacitance: 2.0 pF; Off capacitance: 3.6 pF; Enabled port capacitance: 145 pF
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -65°C to +150°C
- Thermal Resistance: 250°C/W
Buy the Buy Fairchild Analog Switch Part Number FSA3357K8X Online
Purchase the Fairchild SeriesFSA3357K8X analog switch online today to benefit from advanced CMOS technology, low On Resistance, and operation over 1.65V to 5.5V. This space-saving device features break-before-make circuitry, overvoltage control input tolerance up to 7.0V, and a bandwidth of 250 MHz. Ideal for high-speed applications like cell phones, PDAs, and video systems, it ensures signal integrity and reliable switching performance. Order now to improve your electronic projects with this highly efficient, compact analog switch in MicroPak or US8 packages.
Order your Fairchild SeriesFSA3357K8X low-voltage SP3T analog switch today and enhance your high-speed switching circuits with superior performance and reliable control.
Frequently Asked Questions
Where can I buy ONSEMI FSA3357K8X?
You can click on the BUY or RFQ button to purchase FSA3357K8X from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part FSA3357K8X?
You can download the FSA3357K8X datasheet or visit the ONSEMI website for support.
Who is the manufacturer of FSA3357K8X?
ONSEMI
