ONSEMI GBPC1210 Bridge Rectifier
The GBPC1210 is a high-current bridge rectifier series with glass passivated construction for reliable power conversion in industrial applications. It features integral molded heat sinks for excellent heat dissipation, surge overload ratings up to 400 A, and isolated voltage from case to lead over 2500 V. Suitable for use in various AC/DC conversion circuits, these rectifiers comply with UL certifications and have silver (solderable) or nickel-plated terminals. The robust design ensures safe and efficient performance under demanding electrical conditions, making it ideal for industrial power supplies, motor controls, and rectification applications.
ONSEMI GBPC1210 Bridge Rectifier Specifications:
- Maximum Repetitive Reverse Voltage: 50 V to 1000 V depending on model
- Maximum RMS Bridge Input Voltage: 35 V to 700 V
- DC Reverse Voltage: 50 V to 1000 V
- Surge Overload Ratings: 300 A to 400 A
- Isolation Voltage: Over 2500 V from case to lead
- Power Dissipation: 83.3 W
- Thermal Resistance, Junction to Case: 15 °C/W
- Forward Voltage Drop: 1.1 V to 1.7 V at rated currents
- Reverse Current at Rated Voltage: up to 500 μA at 125°C
- Storage Temperature Range: -55°C to +150°C
- Operating Junction Temperature: -55°C to +150°C
- Electrical Certifications: UL Listed #258596
- Case Material: Glass passivated with integral molded heat sink
- Terminal Finish: Silver or Nickel Plated depending on package
Buy the ON Semiconductor GBPC1210 – Reliable Bridge Rectifier for Industrial Applications
Order the ON Semiconductor GBPC1210 series online today to ensure robust power conversion in your industrial and electronic projects. These bridge rectifiers offer high surge overload ratings, excellent thermal management through integrated molded heat sinks, and reliable operation with isolation voltage over 2500 V. Suitable for power supplies, motor drives, and various AC/DC conversion applications, they meet UL certification standards for safety and quality. Purchase now to enhance your equipment’s efficiency, performance, and durability with genuine, fully traceable components from authorized distributors.
Buy ON Semiconductor GBPC1210 now and experience unmatched reliability and performance in high-current rectification for industrial needs.
Frequently Asked Questions
Where can I buy ONSEMI GBPC1210?
You can click on the BUY or RFQ button to purchase GBPC1210 from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part GBPC1210?
You can download the GBPC1210 datasheet or visit the ONSEMI website for support.
Who is the manufacturer of GBPC1210?
ONSEMI
