ONSEMI MJD45H11TF Power Transistor
The MJD45H11TF is a PNP epitaxial silicon transistor designed for general-purpose power and switching applications, such as output or driver stages. It features a surface-mount lead formation, low collector-emitter saturation voltage, and fast switching speeds, making it suitable for power management and industrial use. It supports collector currents up to -8A, collector-emitter voltages of 80V, and junction temperatures up to 150°C. The device is ideal for various switching and amplification tasks in industrial automation and power supply circuits.
ONSEMI MJD45H11TF Power Transistor Specifications:
- Collector-Emitter Voltage: -80 V
- Emitter-Base Voltage: -5 V
- Collector Current (DC): -8 A
- Collector Current (Pulse): -16 A
- Collector Dissipation: 20 W at 25°C
- Junction Temperature: 150°C
- Storage Temperature Range: -55°C to +150°C
- Switching Time (Turn-On): 135 ns
- Fall Time: 100 ns
- Power Derating: Linearly decreases with temperature above 25°C
- Package Type: TO-252 (D-PAK surface-mount)
- Electrical Gain (hFE): 40-80 at Ic = -2A, Vce = -10V
- Capacitance: 230 pF at 1 MHz
- Maximum Power Dissipation: 20 W
- Lead-Formed for surface mounting
- Designed for power switching, drivers and industrial applications
Buy the ON Semiconductor MJD45H11 – Reliable PNP Power Transistor for Industrial Applications
Order the ON Semiconductor MJD45H11TF power transistor online today for your industrial and power management projects. This high-performance PNP device offers fast switching speeds, low saturation voltage, and a robust TO-252 surface-mount package. Designed for output and driver stages, it handles collector currents up to -8A, with high junction temperature tolerance up to 150°C. Whether you're building automation controls or power supplies, this transistor provides dependable operation, ensuring your systems perform efficiently and reliably. Purchase now for seamless integration into your electronic designs.
Buy ON Semiconductor MJD45H11TF now and experience unmatched reliability and performance in power switching and industrial automation applications.
Frequently Asked Questions
Where can I buy ONSEMI MJD45H11TF?
You can click on the BUY or RFQ button to purchase MJD45H11TF from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MJD45H11TF?
You can download the MJD45H11TF datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MJD45H11TF?
ONSEMI
