Phoenix Contact PLCOSC24DC24DC2 Solid-State Relay Module
The PLC-OSC-24DC/24DC/2 is a compact, DIN-rail-mounted solid-state relay interface module designed for industrial automation. It features a zero-voltage turn-on switching mode, high switching power, and screw terminals for secure system connections. The module includes integrated protection, a status LED, plug-in bridges, and a sealed RT III relay for reliable operation. Suitable for PLC systems, it operates within -25°C to 60°C, offers a maximum voltage drop of 200V, and ensures efficient, high-frequency switching with response times of 20 microseconds and turn-off times of 300 microseconds.
Phoenix Contact PLCOSC24DC24DC2 Solid-State Relay Module Specifications:
- Dimensions: Width 6.2mm, Height 80mm, Depth 94mm
- Input Voltage Range: 19.2V DC to 28.8V DC, Nominal 24V DC
- Input Current: 8.5mA at Uy
- Output Voltage Range: 3V DC to 33V DC
- Limiting Continuous Current: 3A
- Maximum Inrush Current: 15A (10 ms)
- Voltage Drop at Max Continuous Current: < 200mV
- Supply Power Dissipation: 0.6W
- Response Time: 20 microseconds
- Turn-Off Time: 300 microseconds
- Operating Temperature: -25°C to 60°C
- Mounting: DIN rail NS 35/7.5
- Protection: Reverse polarity and surge protection
- Standards: IEC 60664, EN 50178, IEC 62103
- Certifications: UL Recognized, UL Listed, cUL Recognized
Buy the Phoenix Contact Series PLC-OSC Solid-State Relay: PLCOSC24DC24DC2
Order the Phoenix Contact PLCOSC24DC24DC2 online today to enhance your industrial automation systems. This reliable DIN rail module offers zero-voltage switching, high switching power, and integrated protection. Its compact design fits seamlessly into control panels, providing fast response times of 20 microseconds and robust operation over a temperature range of -25°C to 60°C. Suitable for high-precision switching tasks, it features screw terminal connections, status LED indicators, and plug-in bridges. Perfect for automated manufacturing, it guarantees efficient, safe, and long-lasting system operations.
Buy Phoenix Contact PLCOSC24DC24DC2 now and experience unmatched reliability and performance in industrial automation solutions.
