TDK-LAMBDA DRB120243A1 Industrial Power Supply
The TDK-Lambda DRB120-24-3-A1 is a resilient three-phase DIN-Rail power supply delivering 120W output power at 24V DC, equipped with efficient overload, short-circuit protection, and robust safety features complying with IEC standards. It features wide input voltage range and high efficiency, suitable for industrial automation, renewable energy, and communication systems. Designed for reliable, long-term operation in demanding environments, it offers multiple connection options, transient protections, and meets EMC and safety standards, making it ideal for industrial control and process automation applications.
TDK-LAMBDA DRB120243A1 Industrial Power Supply Specifications:
- Output Voltage: 24V DC (nominal)
- Output Power: 120W
- Output Current: 5A (nominal), Boost up to 6A/2s
- Adjustment Range: 22.5..29V
- Efficiency: Max. 91.3%
- Input Voltage Range: 3x350..575Vac
- Input Frequency: 47..63Hz
- Inrush Current: Max. 30/39A
- Inrush Energy: Max. 0.3/0.6A·s
- Power Factor: Min. 0.5
- Hold-up Time: Min. 23/43 ms
- Protection: Overvoltage, OVP, Overcurrent, OTP, Short-circuit
- Safety Standards: IEC 61010-1, IEC 62368-1
- EMC Standards: Meets Class B radiated emission, surge immunity
- Dimensions: Width 55mm, Height 129mm, Depth varies with connection type
- Weight: 660g
- Environmental: Operating temp. -25..+55°C, Storage -40..+85°C, Humidity max. 95%
- Certifications: IEC, UL, CB Scheme, China RoHS, WEEE
- Mechanical: Aluminum enclosure, UL 94 V-0 flammability, DIN-Rail compatible
- Service Life: Min. 184,000 hours MTBF
- Safety: Protective earth required, SELV/PELV outputs, electrical insulation paths
Buy the Buy TDK-Lambda Power Supply Part Number DRB120-24-3-A1 Online
Purchase the TDK-Lambda DRB120-24-3-A1 power supply online today and benefit from industrial-grade reliability, high efficiency, and comprehensive protection features. This 120W, 24V DIN-Rail power supply is ideal for automation, renewable energy, and communication applications, ensuring long-term, safe operation. With wide input voltage range, transient protections, and compliance with IEC standards, it guarantees stable power delivery. Elevate your projects with a trusted brand, quick delivery, and excellent support—order now for dependable performance in demanding industrial environments.
Order your TDK-Lambda DRB120-24-3-A1 power supply today and ensure reliable, efficient power for industrial control and automation projects.
