TDK-LAMBDA RWS300B48 power supply
The RWS-300B-48 is a reliable single-output power supply suitable for general-purpose applications. It features enclosed construction, compact size, and provides overcurrent and overvoltage protection. With internal fan cooling, it offers a typical 20ms hold-up time at full load, and an input-to-output isolation resistance exceeding 100 Megohms at 25°C and 70% RH with 500V DC. Adjustable voltage range from 43.2V to 52.8V, ripple noise of 200mV, and UL/IEC safety certifications make it ideal for efficient power management in industrial settings.
TDK-LAMBDA RWS300B48 power supply Specifications:
- Output Voltage Range: 43.2V to 52.8V
- Output Power: 144W
- Output Current: 3A
- Ripple Noise: 200mV
- Efficiency: 86 / 87%
- Input Voltage Range: 85 - 265VAC
- Protection: Overcurrent and Overvoltage protection
- Isolation Resistance: >100M at 25°C & 70% RH with 500VDC
- Cooling: Internal Fan
- Operating Temperature: -20°C to +70°C
- Size: 102 x 41 x 170 mm
- Weight: 900 g
- Safety Certifications: UL, IEC/EN 62368-1
Buy the TDK-Lambda Series RWS B 48V Power Supply: RWS300B48
Purchase the TDK-Lambda RWS300B48 power supply online today and transform your power management system. This 48V single-output model offers superior protection features, high efficiency, and reliable operation ideal for industrial applications. With compact design, excellent isolation resistance, and UL safety approval, it ensures consistent performance. Ideal for automation, manufacturing, and control systems, this power supply guarantees optimal power delivery and durability. Order now for quick delivery and expert support to enhance your project’s reliability and efficiency.
Buy TDK-Lambda RWS300B48 now and experience unmatched reliability and performance for your power management needs.
Frequently Asked Questions
Where can I buy TDK-LAMBDA RWS300B48?
You can click on the BUY or RFQ button to purchase RWS300B48 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part RWS300B48?
You can download the RWS300B48 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of RWS300B48?
TDK-LAMBDA
