TRACO POWER TCL024124C Industrial Power Supply
The TCL024124C is a compact, reliable industrial power supply designed for a wide range of applications including automation, control systems, and industrial equipment. This power supply provides an adjustable 24 VDC output at 10A with high efficiency and low ripple, ensuring stable power delivery even in challenging environments. Featuring UL and CE certifications, it supports universal AC input (85-264 VAC) and has safety features like overload, short circuit, and overvoltage protection. Its DIN-rail mounting capability and rugged plastic housing make installation straightforward in industrial settings.
TRACO POWER TCL024124C Industrial Power Supply Specifications:
- Input Voltage Range: 85-264 VAC / 85-375 VDC
- Output Voltage Range: 24 - 28 VDC (adjustable)
- Output Current: 10A
- Output Power: 240W
- Efficiency: 88% typical
- Ripple and Noise: <50 mV pk-pk
- Protection: Overload, short circuit, overvoltage
- Isolation Voltage: 3000 VAC
- Operating Temperature: -10°C to +70°C (derating above +50°C at 1.7%/K)
- Mounting: DIN-rail or wall mounting
- Certifications: UL, CE, CB, RoHS, Reach
- Enclosure Material: Plastic, 94V-0 rated
- Humidity: 95% non-condensing
- Switching Frequency: 55-180 kHz
- Dimensions: Approx. 146 x 97 x 102 mm
Buy the Traco Power Series TCL24 Power Supply: TCL024124C
Discover the Traco Power TCL024124C power supply, engineered for industrial environments. Its adjustable 24V output, high efficiency, and low ripple ensure stable, reliable power for automation, control panels, and machinery. Featuring UL and CE certifications, it supports universal input voltage (85-264 VAC) and provides robust overload and short-circuit protection. Its compact design with DIN-rail or wall mounting options simplifies installation in demanding industrial settings. Invest in this high-quality power supply for consistent performance, energy savings, and operational peace of mind.
Buy Traco Power TCL024124C now and experience unmatched reliability and performance in industrial automation applications.
Frequently Asked Questions
Where can I buy TRACO POWER TCL024124C?
You can click on the BUY or RFQ button to purchase TCL024124C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TCL024124C?
You can download the TCL024124C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TCL024124C?
TRACO POWER
