TRACO POWER THD104810N DC/DC Converter
The THD 10 series from TracoPower offers compact, high-performance 10W DC/DC converters housed in a 24-pin DIP package with a low profile. These isolated converters feature a wide 2:1 input voltage range suitable for 12V, 24V, or 48V DC inputs, and provide various output voltages including 3.3V, 5.1V, 12V, ±12V, and ±15V, with maximum currents from 470mA to 3A. They deliver efficiency up to 88%, operate at 400kHz, and ensure low ripple and noise with full protections for reliable operation. Their high isolation voltage of 1500VDC, extensive EMC filtering, and compliance with UL, EN, and IEC safety standards make them ideal for industrial and medical applications requiring stable power delivery, compact size, and excellent electrical isolation.
TRACO POWER THD104810N DC/DC Converter Specifications:
- Input Voltage Range: 12V, 24V, 48V DC (wide 2:1 range)
- Output Voltages: 3.3V, 5.1V, 12V, ±12V, ±15V
- Output Current: Up to 3A depending on model
- Efficiency: Up to 88%
- Switching Frequency: 400 kHz
- Ripple and Noise: Max 85mV peak-to-peak at 20 MHz bandwidth
- Isolation Voltage: 1500 VDC for 60 seconds
- Isolation Capacitance: Approximately 1200 pF
- Isolation Resistance: Over 1000 MΩ at 500 VDC
- Operating Temperature: -40°C to +71°C
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Case Material: Metal with non-conductive baseplate
- Soldering Temperature: Max 260°C (1.5mm from case for 10 sec.)
- Certifications: UL/cUL 60950-1, EN 60950-1, IEC 60950-1
- Protection: Short circuit, overload, overvoltage
- EMC Compliance: EN 55022, EN 55024
- Switching Frequency: Approximately 400 kHz
Buy the Buy Traco Power THD Series Part Number THD104810N Online
Purchase the high-quality Traco Power THD 10 series DC/DC converter online today and benefit from its high efficiency up to 88%, wide input voltage range, and extensive protections. This compact, isolated power module provides reliable performance for industrial, medical, or automation systems. With comprehensive EMC shielding and safety certification standards, it ensures compliance and longevity. Its robust design supports operating temperatures from -40°C to +71°C, making it ideal for demanding environments. Secure your power conversion needs easily with fast, hassle-free online ordering today.
Get Traco Power THD104810N today—designed for high reliability, efficiency, and safety in industrial power applications.
Frequently Asked Questions
Where can I buy TRACO POWER THD104810N?
You can click on the BUY or RFQ button to purchase THD104810N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD104810N?
You can download the THD104810N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD104810N?
TRACO POWER
