TRACO POWER THD101210N DC/DC Power Converter
The THD 10 series from TracoPower offers 10W isolated DC/DC converters in a compact 24-pin DIP package, optimized for industrial electronics, instrumentation, and communication systems. They feature a wide 2:1 input voltage range, low ripple and noise, internal EMI filter compliant with EN 55022, class A, and no minimum load requirement. These converters include overvoltage and short circuit protection, operate from -40°C to +71°C, and provide up to 89% efficiency at fixed switching frequencies. With UL, cUL, and IEC certifications, they are ideal for space-constrained, safety-critical applications requiring reliable power conversion.
TRACO POWER THD101210N DC/DC Power Converter Specifications:
- Output Power: 10 Watt
- Input Voltage Range: Wide 2:1 input voltage ratio, nominal inputs of 12V, 24V, 48V DC
- Output Voltages: 3.3V, 5.1V, 12V, ±12V, ±15V
- Efficiency: Up to 89%
- Isolation Voltage: 1500 VDC (input/output)
- Ripple and Noise: 100 mVp-p typ.
- Operating Temperature Range: -40°C to +71°C with derating above +70°C
- Switching Frequency: 400 kHz typical
- Protection: Overvoltage, short circuit, automatic recovery
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, RoHS
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Weight: 173 g
- Isolation Resistance: >1,000 MΩ at 500 VDC
Buy the Buy TracoPower DC/DC Converter Part Number THD101210N Online
Purchase the TracoPower THD101210N DC/DC converter online today to benefit from a reliable, efficient, and compact power solution. Designed for industrial electronics, instrumentation, and communication systems, this 10W converter features a wide input range, high efficiency up to 89%, low ripple and noise, and comprehensive safety certifications. Its robust design includes overload and overvoltage protection, a 1500VDC input/output isolation barrier, and operation from -40°C to +71°C. Essential for space-limited, safety-critical projects, this converter guarantees consistent performance and peace of mind with a 3-year warranty.
Buy TracoPower THD101210N now and ensure reliable power with high efficiency, isolation, and safety features suitable for demanding industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER THD101210N?
You can click on the BUY or RFQ button to purchase THD101210N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD101210N?
You can download the THD101210N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD101210N?
TRACO POWER
